In case an interface has been activated, the system will automatically create the following
queues:
Parameter
high
default
low
Each queue can be con gured as follows:
Parameter
Name
Priority
Bandwidth
Set TOS
You can now con gure and assign any services to each queue. The following parameters
apply:
Parameter
Interface
Queue
Source
Destination
Protocol
Source Port
Destination Port
Type of Service
NB3000-Line-Hd User Manual 4.2
QoS Default Queues
A high priority queue which may hold any latency-critical ser-
vices (such as VoIP)
A default queue which will handle all other services
A low priority queue which may hold less-critical services for
which shaping is intended
QoS Queue Parameters
The name of the QoS queue
A numerical priority for the queue, lower values indicate
higher priorities
The maximum possible bandwidth for this queue in case the
total bandwidth of all queues exceeds the set upstream band-
width of "QoS Interface Parameters"
The TOS/DiffServ value to set on matching packets
QoS Service Parameters
The QoS interface of the queue
The QoS queue to which this service shall be assigned
Speci es a network address and netmask used to match the
source address of packets
Speci es a network address and netmask used to match the
destination (target) address of packets
Speci es the protocol for packets to be matched
Speci es the source port for packets to be matched
Speci es the destination port for packets to be matched
Speci es the TOS/DiffServ for packets to be matched
