5.3.8. Digital I/O
The Digital I/O page displays the current status of the I/O ports and can be used to turn
output ports on or off.
You can apply the following settings:
Parameter
DO1 after reboot
DO2 after reboot
Besides on and off you may keep the default status as the hardware has initialized it after
power-up.
The digital inputs and outputs can also be monitored and controlled by SDK scripts.
NB3000-Line-Hd User Manual 4.2
Figure 5.19.: Digital I/O Ports
Digital I/O Settings
Initial status of DO1 after system has booted
Initial status of DO2 after system has booted
74
