Attention:
You can have concurrent WWAN links which share a common recource like one
WWAN module using SIM cards of different providers. In that case it would
not be possible to nd out if the link with the higher priority is available with-
out putting down the low priority link. Therefor such a link will behave like a
switchover even if con gured as permanent.
For mobile links, it is further possible to pass through the WAN address towards a local host
(also called Drop-In or IP Pass-through). In particular, the rst DHCP client will receive the
public IP address. More or less, the system acts like a modem in such case which can be
helpful in case of rewall issues. Once established, the Web Manager can be reached over
port 8080 using the WAN address but still over the LAN1 interface using port 80.
Parameter
disabled
permanent
on switchover
distributed
Parameter
Operation mode
Weight
Switch-back
1
Bridging interface
NetModule routers provide a feature called IP pass-through (aka Drop-In mode). If enabled,
the WAN address will be be passed-through to the rst DHCP client of the speci ed LAN
interface. As Ethernet-based communication requires additional addresses, we pick an ap-
propriate subnet to talk to the LAN host. In case this overlaps with other addresses of your
WAN network, you may optionally specify the network given by your provider to avoid any
address con icts.
Parameter
IP Pass-through
1
This options requires an Access Point with four address frame format support.
NB3000-Line-Hd User Manual 4.2
WAN Link Operation Modes
Link is disabled
Link is being established permanently
Link is being established on switchover, it will be dialled if pre-
vious links failed
Link is member of a load distribution group
WAN Link Settings
The operation mode of the link
The weight ratio of a distributed link
Speci es the switch-back condition of a switchover link and the
time after an active hotlink will be teared down
If WLAN client, the LAN interface to which the WAN link should
be bridged.
IP Pass-Through Settings
Enables or disables IP pass-through
