Matrix E1 Series (1G694-13)

Configuration Guide

9033754-03

Advertisement

Table of Contents
loading

Related Manuals for Enterasys Matrix E1 1G694-13

Summary of Contents for Enterasys Matrix E1 1G694-13

  • Page 1: Configuration Guide

    Matrix E1 Series (1G694-13) Configuration Guide 9033754-03...
  • Page 3 Enterasys Networks reserves the right to make changes in specifications and other information contained in this document and its web site without prior notice. The reader should in all cases consult Enterasys Networks to determine whether any such changes have been made.
  • Page 4 CAREFULLY READ THIS LICENSE AGREEMENT. This document is an agreement (“Agreement”) between the end user (“You”) and Enterasys Networks, Inc. on behalf of itself and its Affiliates (as hereinafter defined) (“Enterasys”) that sets forth Your rights and obligations with respect to the Enterasys software program (including any accompanying documentation, hardware or media) (“Program”) in the...
  • Page 5 52.227-19 (a) through (d) of the Commercial Computer Software-Restricted Rights Clause and its successors, and (iii) in all respects is proprietary data belonging to Enterasys and/or its suppliers. For Department of Defense units, the Program is considered commercial computer software in accordance with DFARS section 227.7202-3 and its successors, and use, duplication, or disclosure by the Government is subject to restrictions set forth herein.
  • Page 6 Enterasys and, accordingly, You hereby agree to maintain complete books, records and accounts showing (i) license fees due and paid, and (ii) the use, copying and deployment of the Program. You also grant to Enterasys and its authorized representatives, upon reasonable notice, the right to audit and examine during Your normal business hours,...

  • Page 7: Table Of Contents

    Figures ... xiii Tables...xiv ABOUT THIS GUIDE Using This Guide...xv Structure of This Guide ...xvi Related Documents... xvii Document Conventions... xvii Typographical and Keystroke Conventions... xviii INTRODUCTION Overview ... 1-1 Local Management Requirements ... 1-2 Getting Help ... 1-3 SETUP REQUIREMENTS Connecting to a Console Port for Local Management ...
  • Page 8 3.1.6 3.1.7 3.1.8 3.1.9 General Configuration Command Set ... 3-10 3.2.1 3.2.2 3.2.3 3.2.4 3.2.5 3.2.6 Contents Starting and Navigating the Command Line Interface... 3-5 3.1.6.1 Using a Console Port Connection ... 3-5 3.1.6.2 Logging in with a Default User Account ... 3-6 3.1.6.3 Logging in With an Administratively Configured User Account...
  • Page 9 PORT CONFIGURATION Port Configuration Summary... 4-1 4.1.1 4.1.2 4.1.3 Port Configuration Command Set ... 4-6 4.2.1 4.2.2 4.2.3 4.2.4 4.2.5 4.2.6 4.2.7 4.2.8 4.2.9 4.2.10 Port Assignment Scheme ... 4-2 Port String Syntax Used in the CLI... 4-3 Process Overview: Port Configuration... 4-5 Reviewing Port Status ...
  • Page 10 SPANNING TREE CONFIGURATION Spanning Tree Configuration Summary... 5-1 5.1.1 5.1.2 5.1.3 Spanning Tree Configuration Command Set ... 5-3 5.2.1 5.2.2 viii Contents General... 5-1 Spanning Tree Features... 5-2 Process Overview: Spanning Tree Configuration... 5-2 Reviewing and Setting Spanning Tree Bridge Parameters ... 5-3 5.2.1.1 show spantree stats ...
  • Page 11 802.1Q VLAN CONFIGURATION VLAN Configuration Summary ... 6-1 6.1.1 6.1.2 6.1.3 VLAN Configuration Command Set ... 6-3 6.2.1 6.2.2 6.2.3 6.2.4 6.2.5 6.2.6 Port Assignment Scheme ... 6-1 Port String Syntax Used in the CLI... 6-1 Process Overview: 802.1Q VLAN Configuration ... 6-2 Reviewing Existing VLANs ...
  • Page 12 PORT PRIORITY CONFIGURATION Port Priority Configuration Summary... 7-1 7.1.1 7.1.2 Port Priority Configuration Command Set ... 7-2 7.2.1 7.2.2 7.2.3 IGMP CONFIGURATION Multicast Filtering Configuration Summary ... 8-1 8.1.1 IGMP Configuration Command Set... 8-2 8.2.1 8.2.2 8.2.3 About IP Multicast Filtering ... 8-12 Contents Weighted Round Robin (WRR) Priority Queueing...
  • Page 13 NETWORK MANAGEMENT Process overview: Network Management... 9-1 Network Management Command Set ... 9-1 9.2.1 9.2.2 9.2.3 MATRIX E1 CLI QUICK REFERENCE GUIDE Overview ...A-1 CLI Tasks, Commands and Syntax...A-1 INDEX Managing General Device Settings ... 9-1 9.2.1.1 clear config ... 9-2 9.2.1.2 reset ...
  • Page 14 Contents...

  • Page 15: Figures

    Figure Connecting an IBM PC or Compatible Device ... 2-3 Connecting a VT Series Terminal ... 2-4 Connecting to a Modem ... 2-6 Sample Command Default Description ... 3-3 Console Port Initial Startup Screen Before User Authorization ... 3-6 Startup Screen After User Authorization ... 3-7 Using ? to Display Command Options ...
  • Page 16 Tables Table Factory Default Device Settings...3-1 Screen Scrolling Commands ...3-8 Basic Line Editing Commands ...3-9 Optional Ethernet Expansion Modules, Compliance, and Physical Connection ...4-2 show port status Output Details ...4-8 show port counters Output Details...4-11 show spantree stats Output Details ...5-5 show igmp groups Output Details ...8-11 show cdp Output Details ...9-5 show netstat Output Details ...9-16...

  • Page 17: About This Guide

    Welcome to the Enterasys Networks Matrix E1 1G694-13 Configuration Guide. This manual explains how to access the device’s Command Line Interface (CLI) and how to use it to configure the Matrix E1 1G694-13 switch device. Depending on the firmware version used in the Matrix E1 device, some features described in this document may not be supported.

  • Page 18: Structure Of This Guide

    Chapter 802.1Q VLAN according to VLAN, establish VLAN forwarding (egress) lists, route frames according to VLAN ID, and configure ports on the switch as GVRP-aware ports. Chapter Port Priority Configuration, describes how set the transmit priority of each port, display the current traffic class-mapping-to-priority or each port, and to set ports to transmit frames according to selected priority transmit queues.

  • Page 19: Related Documents

    RELATED DOCUMENTS The following Enterasys Networks documents may help you to set up, control, and manage the Matrix E1 device: • Ethernet Technology Guide • Cabling Guide • Matrix E1 1G694-13 Installation Guide • Matrix E1 1G694-13 WebView User’s Guide...

  • Page 20: Typographical And Keystroke Conventions

    TYPOGRAPHICAL AND KEYSTROKE CONVENTIONS bold type Bold type indicates required user input, including command keywords, that must be entered as shown for the command to execute. RETURN Indicates either the ENTER or RETURN key, depending on your keyboard. Indicates the keyboard Escape key. SPACE bar Indicates the keyboard space bar key.

  • Page 21: Introduction

    Enterasys Networks for technical support. Important Notice Depending on the firmware version used in the Matrix E1 1G694-13 device, some features described in this document may not be supported. Refer to the Release Notes shipped with the Matrix E1 device to determine which features are supported.

  • Page 22: Local Management Requirements

    NOTE: This guide describes configuring and managing the Matrix E1 device using CLI commands. For details on using WebView for configuration and management tasks, refer to the Matrix E1 1G694-13 WebView User’s Guide. Chapter 2 provides setup instructions for connecting a terminal or modem to the Matrix E1 device.

  • Page 23: Getting Help

    GETTING HELP For additional support related to this device or document, contact Enterasys Networks using one of the following methods: World Wide Web http://www.enterasys.com/ Phone (603) 332-9400 Internet mail support@enterasys.com To send comments or suggestions concerning this document, contact the Enterasys Networks Technical Writing Department via the following email address: TechWriting@enterasys.com...

  • Page 25: Setup Requirements

    This chapter provides information concerning the following ways to access the Matrix E1 management interface: • Connecting to a Console Port for Local Management connect a PC, a VT series terminal, or a modem to the Enterasys Networks host device. • Using a Telnet Connection connection to access the CLI management interface.

  • Page 26: What Is Needed

    2.1.2 Connecting to an IBM or Compatible Device To connect an IBM PC, or compatible device, running the VT terminal emulation, to an Enterasys Networks module console port 1. Connect the RJ45 connector at one end of the cable (not supplied) to the console port on the Enterasys Networks device.

  • Page 27: Connecting To A Vt Series Terminal

    UTP cable with RJ45 connectors and an optional RJ45-to-DB25 female adapter (PN 9372110), and proceed as follows: 1. Connect the RJ45 connector at one end of the cable to the console port on the Enterasys Networks device. 2. Plug the RJ45 connector at the other end of the cable into the RJ45-to-DB25 female adapter.
  • Page 28 Connecting to a VT Series Terminal 4. Turn on the terminal and access the setup directory. Set the following parameters on your terminal: Parameter Mode Transmit Bits Parity Stop Bit 5. When these parameters are set, the Matrix E1 startup screen will display. Figure 2-2 Connecting a VT Series Terminal À...

  • Page 29: Connecting To A Modem

    RJ45 connectors and an optional RJ45-to-DB25 male adapter (PN 9372112), and proceed as follows: 1. Connect the RJ45 connector at one end of the cable to the modem port on the Enterasys Networks device. 2. Plug the RJ45 connector at the other end of the cable into the RJ45-to-DB25 male adapter.
  • Page 30 Connecting to a Modem Figure 2-3 Connecting to a Modem À RJ45 Modem Port Modem Matrix E1 Series (1G694-13) Configuration Guide  Á RJ45-to-DB25 Modem Adapter UTP Cable with RJ45 Connectors Reset Console Ä Ã RJ45 Console Port...

  • Page 31: Adapter Wiring And Signal Assignments

    2.1.5 Adapter Wiring and Signal Assignments Console Port Adapter Wiring and Signal Diagram RJ45 VT Series Port Adapter Wiring and Signal Diagram RJ45 Conductor Blue Green Orange Yellow DB25 Conductor Blue Yellow Green Orange Matrix E1 Series (1G694-13) Configuration Guide Adapter Wiring and Signal Assignments Signal Receive (RX)

  • Page 32: Using A Telnet Connection

    Adapter Wiring and Signal Assignments Modem Port Adapter Wiring and Signal Diagram RJ45 Conductor Blue Orange Green Yellow Gray USING A TELNET CONNECTION Once the Matrix E1 device has a valid IP address, you can establish a Telnet session from any TCP/IP based node on the network.

  • Page 33: Startup And General Configuration

    Startup and General Configuration This chapter describes factory default settings and the Startup and General Configuration set of commands. STARTUP AND GENERAL CONFIGURATION SUMMARY At startup, the Matrix E1 device is configured with many defaults and standard features. The following sections provide information on how to review and change factory defaults, and how to customize basic system settings to adapt to your work environment.
  • Page 34 Factory Default Settings Table 3-1 Factory Default Device Settings (Continued) Device Feature Password Port auto-negotiation Port enable/disable Port trap QoS weighted round-robin (WRR) Spanning Tree Spanning Tree edge port administrative status Spanning Tree edge port delay Spanning Tree forward delay Spanning Tree hello interval Does not apply to MATRIX...

  • Page 35: Command Defaults" Descriptions

    Table 3-1 Factory Default Device Settings (Continued) Device Feature Spanning Tree transmit hold count Spanning Tree version. System baud rate System contact System location System name Terminal VLAN ID WebView WebView port 3.1.2 “Command Defaults” Descriptions Each command description in this guide includes a section entitled “Command Defaults” which contains different information than the factory default settings on the device as described in Table 3-1.

  • Page 36: Cli Command Modes

    NOTE: This guide describes configuring and managing the Matrix E1 device using CLI commands. For details on using WebView (Enterasys Networks’ embedded web server) for configuration and management tasks, refer to the Matrix E1 1G694-13 WebView User’s Guide. By default WebView is enabled on TCP port number 80 of the Matrix E1 device. You can verify WebView status, enable or disable WebView, and reset the WebView port as described below.

  • Page 37: Process Overview: Cli Startup And General Configuration

    This example shows how to set the WebView port to 100. Matrix>set webview port 100 Webview port set to 100. 3.1.5 Process Overview: CLI Startup and General Configuration Use the following steps as a guide to the startup and general configuration process: 1.

  • Page 38: Logging In With A Default User Account

    Leave this string blank and press ENTER. The notice of authorization and the Matrix prompt displays as shown in Figure Figure 3-2 Console Port Initial Startup Screen Before User Authorization (c)Copyright ENTERASYS Networks, Inc. 2001 Matrix 1G694-13 POST Version ver 01.00.08 Loading primary functional image ... PASSED Application image loaded to CPU SDRAM.

  • Page 39: Logging In With An Administratively Configured User Account

    The notice of authorization and the Matrix prompt displays as shown in Figure 3-3 Startup Screen After User Authorization Username:rw Password: waiting for authorization... **************************************** Enterasys Networks, Inc. Rochester, NH 03866-5005 USA **************************************** Matrix> Starting and Navigating the Command Line Interface Matrix 1G694-13 P.O.

  • Page 40: Getting Help With Cli Syntax

    Getting Help with CLI Syntax For information about setting the IP address, refer to Refer to the instructions included with the Telnet application for information about establishing a Telnet session. 3.1.7 Getting Help with CLI Syntax As shown in Figure 3-4, you can display command options, such as syntax details and a list of commands that share the same initial keywords, by entering a question mark (?) in the CLI command string.

  • Page 41: Basic Line Editing Commands

    3.1.9 Basic Line Editing Commands The CLI supports EMACs-like line editing commands. commands. Table 3-3 Basic Line Editing Commands Key Sequence Command Ctrl+A Move cursor to beginning of line. Ctrl+B Move cursor back one character. Ctrl+C Abort command. Ctrl+D Delete character. Ctrl+E Move cursor to end of line.

  • Page 42: General Configuration Command Set

    Setting the Login Password GENERAL CONFIGURATION COMMAND SET 3.2.1 Setting the Login Password Purpose To change the login password on the CLI. Command The command needed to set the login password is listed below and described in the associated section as shown. •...

  • Page 43: Setting Basic System Information

    Startup and General Configuration Setting Basic System Information 3.2.2 Setting Basic System Information Purpose To display and set the basic system information, including time, contact name, terminal output, baud rate and version information, to display or set the local host IP address, and to download a new firmware image to the device.

  • Page 44: Show System

    Setting Basic System Information 3.2.2.1 show system Use this command to display system information. show system Syntax Description None. Command Defaults None. Command Mode Read-Only. Example This example shows how to display system information: Matrix>show system Power Supply Status ------------------------ PS1 - Operational PS2 - Operational System Baud : 9600.

  • Page 45: Show Time

    3.2.2.2 show time Use this command to display the current time of day in the system clock. show time Syntax Description None. Command Defaults None. Command Mode Read-Only. Example This example shows how to display the current time: Matrix>show time Thu 11/06/2001 08:24:28 The output shows the day of the week, month, day, year, hour, minutes, and seconds.

  • Page 46: Set Time

    Setting Basic System Information 3.2.2.3 set time Use this command to change the time of day on the system clock. set time [day_of_week][mm/dd/yyyy][hh:mm:ss] Syntax Description day_of_week mm/dd/yyyy hh:mm:ss Command Defaults This command has no default setting. Command Mode Read-Write. Example This example shows how to set the system clock to Saturday, October 31, 2003, 7:50 a.m: Matrix>set time sat 10/31/2003 7:50 Sat Oct 31 1998, 07:50:00...

  • Page 47: Show Version

    3.2.2.4 show version Use this command to display hardware and firmware information. Refer to instructions on how to download a firmware image. show version Syntax Description None. Command Defaults None. Command Mode Read-Only. Example This example shows how to display version information: Matrix>show version Slot Ports...

  • Page 48: Set System Name

    Setting Basic System Information 3.2.2.5 set system name Use this command to configure a name for the system. set system name “name_string” Syntax Description name_string Command Defaults None. Command Mode Read-Write. Usage Guidelines None. Example This example shows how to set the system name to Information Systems: Matrix>set system name “Information Systems”...

  • Page 49: Set System Location

    3.2.2.6 set system location Use this command to identify the location of the system. set system location “location_string” Syntax Description location_string Command Defaults None. Command Mode Read-Write. Example This example shows how to set the system location string: Matrix>set system location “Bldg N32-04 Closet 9 Alpha Sierra” System location set.

  • Page 50: Set System Contact

    Setting Basic System Information 3.2.2.7 set system contact Use this command to identify a contact person for the system. set system contact “contact_string” Syntax Description contact_string Command Defaults None. Command Mode Read-Write. Example This example shows how to set the system contact string: Matrix>set system contact “Joe Smith”...

  • Page 51: Set Terminal

    3.2.2.8 set terminal Use this command to set the number of columns and rows of the terminal connected to the console port of the device. This information is used to control the output of the CLI itself. set terminal {rows num_rows | cols num_cols} Syntax Description rows num_rows...

  • Page 52: Set System Baud

    Setting Basic System Information 3.2.2.9 set system baud Use this command to set the console port baud rate. set system baud rate Syntax Description rate Command Defaults None. Command Mode Read-Write. Example This example shows how to set the system baud rate to 19200: Matrix>set system baud 19200 System console port baud rate set to 19200.

  • Page 53: Show Ip Address

    3.2.2.10 show ip address Use this command to display the local host port IP address and the system mask. show ip address Syntax Description None. Command Defaults None. Command Mode Read-Only. Example This example shows how to display the host port IP address and the system mask. Matrix>show ip address System IP System Mask...

  • Page 54: Set Ip Address

    Setting Basic System Information 3.2.2.11 set ip address Use this command to set the local host IP address and subnet mask. set ip address ip_addr [ip_mask] Syntax Description ip_addr ip_mask Command Defaults If not specified, ip_mask will be set to 255.255.0.0. Command Mode Read-Write.

  • Page 55: Downloading A Firmware Image

    To download device firmware via the serial port, proceed as follows: 1. Reset the device’s dip switch 6 as detailed in Appendix B: “Mode Switch Bank Settings” in the Matrix E1 1G694-13 Installation Guide. 2. With the console port connected, reset the device by powering the device off and then on.

  • Page 56: Downloading Via Tftp

    Downloading a Firmware Image 5. Send the file using the XMODEM protocol from your computer application (the procedure varies depending upon the application used). 6. When the XMODEM procedure finishes, the following messages are displayed: Performing checksum of received image ... PASSED Programming primary functional image to flash ...

  • Page 57: Command Mode

    Updating flashROM image at 0xFF500000 ... Image update successful. Restarting system... Saving persistent data ++++++++++++++++++++++++++++++++++++++++++++++++++ (c)Copyright ENTERASYS Networks, Inc. 2001 Matrix 1G694-13 POST Version 01.00.00 Application image found in Flash memory. Loading functional image ... Application image loaded to CPU SDRAM.

  • Page 58: Setting Snmp Community Names

    Setting SNMP Community Names 3.2.4 Setting SNMP Community Names Purpose To set SNMP Management community names and access policies. Community names act as passwords to remote SNMP management. Access is controlled by enacting either of two levels of security authorization (read-only or read-write.) NOTE: Read-write access gives the user full management privileges, allows existing passwords to be changed, and all modifiable MIB objects to be edited.

  • Page 59: Show Community

    3.2.4.1 show community Use this command to display SNMP community names and access policies. show community Syntax Description None. Command Defaults None. Command Mode Read-Only. Example This example shows how to display community names and access policies: Matrix>show community Community Name ------------------ Public Private...

  • Page 60: Set Community

    Setting SNMP Community Names 3.2.4.2 set community Use this command to set SNMP community names and access policies. set community community_name access_ policy Syntax Description community_name access_ policy Command Defaults None. Command Mode Read-write. Example This example shows how to set the community name “green” for read-write access. Matrix>set community green rw Community record added.

  • Page 61: Clear Community

    3.2.4.3 clear community Use this command to delete SNMP community names. clear community community_name Syntax Description community_name Command Defaults None. Command Mode Read-Write. Example This example shows how to delete the community name “green.” Matrix>clear community green Community record cleared. Specifies the SNMP management user access name to be deleted.

  • Page 62: Setting Snmp Traps

    Setting SNMP Traps 3.2.5 Setting SNMP Traps Purpose To assign IP addresses where SNMP traps will be sent. The device can send messages to multiple network management stations to alert users of status changes. For details on the types of traps this device supports, refer to the appropriate Matrix E1 Release Notes.

  • Page 63: Show Trap

    3.2.5.1 show trap Use this command to display SNMP trap configuration information. show trap Syntax Description None. Command Defaults None. Command Mode Read-Only Example This example shows how to use the show trap command. It shows that there are two SNMP traps enabled.

  • Page 64: Set Trap

    Setting SNMP Traps 3.2.5.2 set trap Use this command to configure an SNMP trap assigned to an IP address. set trap ip_ address community_name {enable | disable} Syntax Description ip_address community_name enable | disable Command Defaults None. Command Mode Read-Write. Example This example shows how to enable a trap on IP address 172.29.65.123 in the “blue”...

  • Page 65: Clear Trap

    3.2.5.3 clear trap Use this command to clear an SNMP trap assigned to an IP address. clear trap ip_address Syntax Description ip_address Command Defaults None. Command Mode Read-Write Example This example shows how to clear the trap assigned to IP address 172.29.65.123. Matrix>clear trap 172.29.65.123 Trap cleared.

  • Page 66: Exit

    Closing the CLI 3.2.6.1 exit Use this command to leave a CLI session. exit NOTE: Device timeout occurs after five minutes of user inactivity, automatically closing your CLI session. Syntax Description None. Command Defaults None. Command Mode Read-Only. Example This example shows how to exit a CLI session: Matrix>exit Connection closed by foreign host.

  • Page 67: Port Configuration

    This chapter describes the Port Configuration set of commands and how to use them. PORT CONFIGURATION SUMMARY The Matrix E1 1G694-13 features a fixed front panel of twelve 1-Gigabit Ethernet ports and an optional expansion module slot with one 10-Gigabit Ethernet uplink port.

  • Page 68: Port Assignment Scheme

    The expansion module and fixed front panel port numbering scheme used when configuring Matrix E1 1G694-13 port functionality is shown in as 0 for being fixed ports on the front panel. In this numbering scheme, front panel port 8 is expressed as 0.8 in the CLI syntax.

  • Page 69: Port String Syntax Used In The Cli

    The highest port number that can be entered is dependent on the number of ports in a slot location. For example: The Matrix E1 1G694-13 has 12 front panel ports (location 0), and 1 port in the expansion module (slot location 1).
  • Page 70 Port String Syntax Used in the CLI Examples This example shows the port_string syntax for specifying Gigabit Ethernet port 3 in the device’s fixed front panel. ge.0.3 This example shows the port_string syntax for specifying Gigabit Ethernet ports 1 through 10 in the device’s fixed front panel.

  • Page 71: Process Overview: Port Configuration

    Port Configuration Process Overview: Port Configuration 4.1.3 Process Overview: Port Configuration Use the following steps as a guide in the port configuration process: 1. Reviewing port status (Section 4.2.1) 2. Disabling / enabling ports (Section 4.2.2) 3. Setting auto negotiation (Section 4.2.3) 4.

  • Page 72: Port Configuration Command Set

    Reviewing Port Status PORT CONFIGURATION COMMAND SET 4.2.1 Reviewing Port Status Purpose To display port operating status, duplex mode, speed and port type, and statistical information about traffic received and transmitted through one port or all ports on the device. Commands The commands needed to review port status are listed below and described in the associated sections as shown.

  • Page 73: Show Port Status

    4.2.1.1 show port status Use this command to display port status information. show port status [port_string] Syntax Description port_string Command Defaults If port_string is not specified, status information for all ports will be displayed. Command Mode Read-Only. Example This example shows how to display status information for Gigabit Ethernet front panel ports 8 through 11: Matrix>show port status ge.0.8-11 Port...
  • Page 74 Reviewing Port Status Table 4-2 show port status Output Details Output Port Oper Status Admin Status Duplex Speed Type Matrix E1 Series (1G694-13) Configuration Guide What It Displays... Port designation. For a detailed description of possible port_string values, refer to Whether the port has a valid link.

  • Page 75: Show Port Counters

    4.2.1.2 show port counters Use this command to display counter statistics detailing traffic through the switch device and through all MIB2 network devices. show port counters [port_string] [mib2 | switch] Syntax Description port_string mib2 | switch Command Defaults If port_string is not specified, counter statistics will be displayed for all ports. If mib2 or switch is not specified, all counter statistics will be displayed for the specified port(s).
  • Page 76 Out Errors: Out Queue Length: 802.1Q Switch Counters: Frames Received: Frames Transmitted: This example shows how to display all port counter statistics related to traffic through the switch device. Matrix>show port counters ge.0.1 switch Port: ge.0.1 802.1Q Switch Counters: ----------------------...

  • Page 77: Disabling / Enabling Ports

    Table 4-3 show port counters Output Details Value Port Bridge Port 802.1Q Switch Counters 4.2.2 Disabling / Enabling Ports Purpose To disable and re-enable one or more ports. By default, all ports are enabled at device startup. You may need to disable ports in the event of network problems or to put ports “off-line” during certain configuration procedures.

  • Page 78: Set Port Disable

    Disabling / Enabling Ports 4.2.2.1 set port disable Use this command to administratively disable one or more ports. set port disable port_string Syntax Description port_string Command Defaults None. Command Mode Read-Write. Example This example shows how to disable Gigabit Ethernet front panel port 1: Matrix>set port disable ge.0.1 Port ge.0.1 is administratively disabled.

  • Page 79: Set Port Enable

    4.2.2.2 set port enable Use this command to administratively enable one or more ports. set port enable port_string Syntax Description port_string Command Defaults None. Command Mode Read-Write. Example This example shows how to enable Gigabit Ethernet front panel port 1: Matrix>set port enable ge.0.1 Port ge.0.3 is administratively enabled.

  • Page 80: Setting Port Auto-Negotiation

    Setting Port Auto-Negotiation 4.2.3 Setting Port Auto-Negotiation Purpose To determine whether auto-negotiation is enabled or disabled for the specific port and to set the state, and to display or set a port’s advertised mode of operation. During auto-negotiation, the port “tells”...

  • Page 81: Show Port Negotiation

    4.2.3.1 show port negotiation Use this command to display the status of auto-negotiation for one or more ports. show port negotiation [port_string] Syntax Description port_string Command Defaults If port_string is not specified, auto-negotiation status for all ports will be displayed. Command Mode Read-Only.

  • Page 82: Set Port Negotiation

    Setting Port Auto-Negotiation 4.2.3.2 set port negotiation Use this command to enable or disable auto-negotiation on one or more ports. set port negotiation port_string {disable | enable} Syntax Description port_string disable | enable Command Defaults None. Command Mode Read-Write. Example This example shows how to disable auto-negotiation on Gigabit Ethernet front panel port 11: Matrix>set port negotiation ge.0.11 disable Auto negotiation disabled for port ge.0.11.

  • Page 83: Setting Flow Control

    4.2.4 Setting Flow Control Purpose To display, enable or disable flow control. Flow control is used to manage the transmission between two devices as specified by IEEE 802.3x to prevent receiving ports from being overwhelmed by frames from transmitting devices. Commands The commands needed to set flow control are listed below and described in the associated section as shown.

  • Page 84: Show Port Flowcontrol

    Setting Flow Control 4.2.4.1 show port flowcontrol Use this command to display the flow control state for one or more ports. show port flowcontrol [port_string] Syntax Description port_string Command Defaults If port_string is not specified, flow control statistics for all ports will be displayed. Command Mode Read-Only.

  • Page 85: Set Port Flowcontrol

    4.2.4.2 set port flowcontrol Use this command to enable or disable flow control for one or more ports. set port flowcontrol port_string {disable | enable} Syntax Description port_string disable | enable Command Defaults None. Command Mode Read-Write. Example This example shows how to enable flow control on Gigabit Ethernet front panel ports 1 through 4: Matrix>set port flowcontrol ge.0.1-4 enable Port flow control enabled for port ge.0.1.

  • Page 86: Enabling / Disabling Jumbo Frame Support

    (Section 4.2.5.2) NOTE: Jumbo frame support is available on Matrix E1 1G694-13 devices equipped with hardware version 2 and higher. Earlier hardware versions will display the jumbo frame commands, but will not allow jumbo frames to be enabled. To determine your device’s hardware version, use the show version command as described in...

  • Page 87: Show Jumbo

    4.2.5.1 show jumbo Use this command to display the status of jumbo frame support on the device. show jumbo Syntax Description None. Command Defaults None. Command Mode Read-Only. Example This example shows how to display the status of jumbo frame support: Matrix>show jumbo Jumbo frames are currently disabled.

  • Page 88: Set Jumbo

    Enabling / Disabling Jumbo Frame Support 4.2.5.2 set jumbo Use this command to enable or disable jumbo frame support on the device. set jumbo {enable | disable} Syntax Description enable | disable Command Defaults None. Command Mode Read-Write. Example This example shows how to enable jumbo frame support on the device: Matrix>set jumbo enable Jumbo frames enabled.

  • Page 89: Setting Port Traps

    4.2.6 Setting Port Traps Purpose To display the status, and to enable or disable an SNMP link trap on one or more ports. This operation is typically used to alert the system manager of a change in the link status of the port. Command The commands needed to display, enable or disable port traps are listed below and described in the associated section as shown.

  • Page 90: Show Port Trap

    Setting Port Traps 4.2.6.1 show port trap Use this command to display the status of an SNMP link trap on one or more ports. show port trap [port_string] Syntax Description port_string Command Defaults If no port_string is specified, the trap status for all ports is displayed. Command Mode Read-Write.

  • Page 91: Set Port Trap

    4.2.6.2 set port trap Use this command to enable or disable an SNMP link trap on one or more ports. set port trap port_string {enable | disable} Syntax Description port_string enable | disable Command Defaults None. Command Mode Read-Write. Example This example shows how to disable the SNMP link trap for Gigabit Ethernet front panel port 3: Matrix>set port trap ge.0.3 disable SNMP link traps disabled for port ge.0.3...

  • Page 92: Overview: Port Mirroring

    The Matrix E1 allows you to mirror the traffic being switched on a port for the purposes of network traffic analysis and connection assurance. When port mirroring is enabled, one port becomes a monitor port for another port within the switch. When configuring port mirroring on this device, note that •...

  • Page 93: Show Port Mirroring

    4.2.8.1 show port mirroring Use this command to display the source and target ports for mirroring, and whether mirroring is currently enabled or disabled for those ports. show port mirroring Syntax Description None. Command Defaults None. Command Mode Read-Only. Example This example shows that Gigabit Ethernet front panel port 4 is configured as a source port, that port 11 is configured as the target port to monitor all of port 4’s activity, and that mirroring is disabled.

  • Page 94: Set Port Mirroring

    Port Mirroring Commands 4.2.8.2 set port mirroring Use this command to designate a single port pair (source and target ports) for mirroring. set port mirroring port_string port_string {disable | enable} Syntax Description port_string disable | enable Command Defaults None. Command Mode Read-write.

  • Page 95: Overview: Port Trunking

    4.2.9 Overview: Port Trunking Port trunks can be used to increase the bandwidth of a network connection and to ensure fault recovery. The Matrix 1G694-13 allows you to configure up to six trunks (of two ports per trunk) on the device. It also allows you to configure all 12 Gigabit Ethernet ports into an aggregate connection.

  • Page 96: Setting Port Trunking

    Setting Port Trunking 4.2.10 Setting Port Trunking Purpose To display trunking information, to create and delete trunks on the device, and to display and configure port settings for a particular trunk. Commands The commands needed to configure port trunking are listed below and described in the associated section as shown.

  • Page 97: Show Trunk

    4.2.10.1 show trunk Use this command to display trunking information for the device. show trunk [trunk_name] Syntax Description trunk_name Command Defaults If trunk_name is not specified, information for all trunks will be displayed. Command Mode Read-Only. Example This example shows how to display trunking information for the “blue” trunk: Matrix>show trunk blue trunk port: 7 trunk port: 8...

  • Page 98: Set Trunk

    Setting Port Trunking 4.2.10.2 set trunk Use this command to create, enable and disable trunks. set trunk trunk_name {create | disable | enable} Syntax Description trunk_name create | disable | enable Command Defaults None. Command Mode Read-Write. Example This example shows how to create a trunk named “blue”: Matrix>set trunk blue create Successful trunking operation for blue.

  • Page 99: Clear Trunk

    4.2.10.3 clear trunk Use this command to delete a specific trunk from the switch. clear trunk trunk_name Syntax Description trunk_name Command Defaults None. Command Mode Read-Write. Example This example shows how to delete the “green” trunk from the device Matrix>clear trunk green Trunk green deleted.

  • Page 100: Set Trunk Port

    Setting Port Trunking 4.2.10.4 set trunk port Use this command to add a trunk port to an existing trunk set trunk port trunk_name port_string Syntax Description trunk_name port_string Command Defaults None. Command Mode Read-Write. Example This example shows how to add Gigabit Ethernet front panel ports 3 through 6 to the “blue” trunk. Matrix>set trunk port blue ge.0.3-6 Port ge.0.3 added to trunk blue.

  • Page 101: Clear Trunk Port

    4.2.10.5 clear trunk port Use this command to remove a port from a trunk. clear trunk port trunk_name priority_string Syntax Description trunk_name port_string Command Defaults None. Command Mode Read-Write. Example This example shows how to delete Gigabit Ethernet front panel ports 5 through 7 from the “blue” trunk.

  • Page 103: Spanning Tree Configuration

    It selects one switch as the root of a Spanning Tree-connected active topology and assigns port roles to individual ports of the switch, depending on whether that port is part of the active topology.

  • Page 104: Spanning Tree Features

    1. Reviewing and setting Spanning Tree bridge (device) parameters 2. Reviewing and setting Spanning Tree port parameters NOTE: The term “bridge” is used as an equivalent to the term “switch” or “device” in this document. Matrix E1 Series (1G694-13) Configuration Guide (Section 5.2.1)

  • Page 105: Spanning Tree Configuration Command Set

    SPANNING TREE CONFIGURATION COMMAND SET 5.2.1 Reviewing and Setting Spanning Tree Bridge Parameters Purpose To display and set Spanning Tree bridge parameters, including device priorities, hello time, maximum age time, forward delay, path cost, topology change trap suppression, real time message age and transmit hold count.

  • Page 106: Show Spantree Stats

    Reviewing and Setting Spanning Tree Bridge Parameters 5.2.1.1 show spantree stats Use this command to display general Spanning Tree information for the device and one or more ports. show spantree stats [active | port port_string] Syntax Description active port port_string Command Defaults If active or port are not specified, no port-specific information will be displayed.
  • Page 107 This example shows how to display Spanning Tree information for front panel port 3: Matrix>show spantree stats port ge.0.3 Spanning tree Designated Root MacAddr Designated Root Priority Designated Root Cost Designated Root Port Root Max Age Root Hello Time Root Hold Time Root Forward Delay Bridge ID Mac Address Bridge ID Priority...
  • Page 108 Reviewing and Setting Spanning Tree Bridge Parameters Table 5-1 show spantree stats Output Details (Continued) Output Root Hello Time Root Hold Time Root Forward Delay Bridge ID Mac Address Bridge ID Priority Bridge Max Age Bridge Hello Time Bridge Forward Delay Topology Change Count Port State...

  • Page 109: Set Spantree

    Priority 5.2.1.2 set spantree Use this command to globally enable or disable the Spanning Tree algorithm on the switch. set spantree {disable | enable} NOTE: By default, Spanning Tree is enabled (globally and on all ports.) To display the current status of Spanning Tree on the device or on one or more ports, use the show...

  • Page 110: Show Spantree Version

    Reviewing and Setting Spanning Tree Bridge Parameters 5.2.1.3 show spantree version Use this command to display the current version of the Spanning Tree protocol running on the device. show spantree version Syntax Description None. Command Defaults None. Command Mode Read-Only. Example This example shows how to display Spanning Tree version information: Matrix>show spantree version...

  • Page 111: Set Spantree Version

    5.2.1.4 set spantree version Use this command to set the version of the Spanning Tree protocol to RSTP (Rapid Spanning Tree Protocol) or to STP 802.1D-compatible. set spantree version {rstp | stpcompatible} NOTE: In most networks, Spanning Tree version should not be changed from its default setting of rstp (Rapid Spanning Tree Protocol) mode.

  • Page 112: Set Spantree Priority

    Reviewing and Setting Spanning Tree Bridge Parameters 5.2.1.5 set spantree priority Use this command to set the device’s Spanning Tree priority. The device with the highest priority becomes the Spanning Tree root device. If all devices have the same priority, the device with the lowest MAC address will then become the root device.

  • Page 113: Set Spantree Hello

    5.2.1.6 set spantree hello Use this command to set the device’s Spanning Tree hello time, This is the time interval (in seconds) the device will transmit BPDUs indicating it is active. set spantree hello interval Syntax Description interval Command Defaults None.

  • Page 114: Set Spantree Maxage

    Reviewing and Setting Spanning Tree Bridge Parameters 5.2.1.7 set spantree maxage Use this command to set the bridge maximum aging time. This is the maximum time (in seconds) a device can wait without receiving a configuration message (bridge “hello”) before attempting to reconfigure.

  • Page 115: Set Spantree Fwddelay

    5.2.1.8 set spantree fwddelay Use this command to set the Spanning Tree forward delay. This is the maximum time (in seconds) the root device will wait before changing states (i.e., listening to learning to forwarding). This delay is required because every device must receive information about topology changes before it starts to forward frames.

  • Page 116: Show Spantree Edgeportdelay

    Reviewing and Setting Spanning Tree Bridge Parameters 5.2.1.9 show spantree edgeportdelay Use this command to display the status of the Spanning Tree edge port delay function. show spantree edgeportdelay Syntax Description None. Command Defaults None. Command Mode Read-Only. Example This example shows how to display the status of the edge port delay function: Matrix>show spantree edgeportdelay Edge port delay is currently enabled.

  • Page 117: Set Spantree Edgeportdelay

    5.2.1.10 set spantree edgeportdelay Use this command to enable or disable the edge port delay function, which causes an edge port to delay (by 2 “hello” periods) moving to a forwarding state. set spantree edgeportdelay {disable | enable} Syntax Description disable | enable Command Defaults None.

  • Page 118: Show Spantree Legacypathcost

    Reviewing and Setting Spanning Tree Bridge Parameters 5.2.1.11 show spantree legacypathcost Use this command to display the status of the legacy (802.1D) path cost setting. show spantree legacypathcost Syntax Description None. Command Defaults None. Command Mode Read-Only. Example This example shows how to display the status of the legacy path cost setting: Matrix>show spantree legacypathcost Legacy path cost is currently enabled.

  • Page 119: Set Spantree Legacypathcost

    5.2.1.12 set spantree legacypathcost Use this command to enable or disable legacy (802.1D) path cost values. set spantree legacypathcost {disable | enable}) Syntax Description disable | enable Command Defaults None. Command Mode Read-Write. Example This example shows how to set the default path cost values to 802.1D: Matrix>set spantree legacypathcost enable Legacy path cost ENABLED.

  • Page 120: Show Spantree Tctrapsuppress

    Reviewing and Setting Spanning Tree Bridge Parameters 5.2.1.13 show spantree tctrapsuppress Use this command to display the status of topology change trap suppression on Rapid Spanning Tree edge ports. show spantree tctrapsuppress Syntax Description None. Command Defaults None. Command Mode Read-Only.

  • Page 121: Set Spantree Tctrapsuppress

    By default, RSTP non-edge (bridge) ports that transition to forwarding or blocking cause the switch to issue a topology change trap. When topology change trap suppression is enabled, which is the device default, edge ports (such as end station PCs) are prevented from sending topology change traps.

  • Page 122: Show Spantree Rtmsgage

    Reviewing and Setting Spanning Tree Bridge Parameters 5.2.1.15 show spantree rtmsgage Use this command to display the status of real time BPDU message age mode. show spantree rtmsgage Syntax Description None. Command Defaults None. Command Mode Read-Only. Example This example shows how to display the status of real time BPDU message age mode: Matrix>show spantree rtmsgage Real time message age mode is currently disabled.

  • Page 123: Set Spantree Rtmsgage

    5.2.1.16 set spantree rtmsgage Use this command to enable or disable real time BPDU message age mode. set spantree rtmsgage {enable | disable} Syntax Description enable | disable Command Defaults None. Command Mode Read-Write. Example This example shows how to enable real time BPDU message age mode: Matrix>set spantree rtmsgage enable Success setting real time message age mode to ENABLE.

  • Page 124: Show Spantree Txholdcount

    Reviewing and Setting Spanning Tree Bridge Parameters 5.2.1.17 show spantree txholdcount Use this command to display the maximum BPDU transmission rate. show spantree txholdcount Syntax Description None. Command Defaults None. Command Mode Read-Only. Example This example shows how to display the transmit hold count setting: Matrix>show spantree txholdcount Tx hold count = 3.

  • Page 125: Set Spantree Txholdcount

    5.2.1.18 set spantree txholdcount Use this command to set the maximum BPDU transmission rate. This is the number of BPDUs which will be transmitted before transmissions are subject to a one-second timer. set spantree txholdcount txholdcount Syntax Description txholdcount Command Defaults None.

  • Page 126: Reviewing And Setting Spanning Tree Port Parameters

    Reviewing and Setting Spanning Tree Port Parameters 5.2.2 Reviewing and Setting Spanning Tree Port Parameters Purpose To display and set Spanning Tree port or module parameters, including enabling or disabling the Spanning Tree algorithm on one or more ports, displaying blocked ports, displaying and setting Spanning Tree port priorities and costs, configuring edge port parameters, and setting point-to-point protocol mode.

  • Page 127: Set Spantree Portadmin

    5.2.2.1 set spantree portadmin Use this command to enable or disable the Spanning Tree algorithm on one or more ports. set spantree portadmin port_string {enable | disable} Syntax Description port_string enable | disable Command Defaults None. Command Mode Read-Write. Example This example shows how to disable Spanning Tree on front panel port 12: Matrix>set spantree portadmin ge.0.12 disable Success setting spanning tree protocol to DISABLE for port ge.0.12.

  • Page 128: Show Spantree Blockedports

    Reviewing and Setting Spanning Tree Port Parameters 5.2.2.2 show spantree blockedports Use this command to display the blocked ports in a Spanning Tree. A port in this state does not participate in the transmission of frames, thus preventing duplication arising through multiple paths existing in the active topology of the bridged LAN.

  • Page 129: Show Spantree Portpri

    5.2.2.3 show spantree portpri Use this command to show the Spanning Tree priority for one or more ports. If the path cost for all ports on a device is the same, the port with the highest priority (i.e., lowest value) will be configured as an active link in the Spanning Tree.

  • Page 130: Set Spantree Portpri

    Reviewing and Setting Spanning Tree Port Parameters 5.2.2.4 set spantree portpri Use this command to set a port’s priority for use in the Spanning Tree algorithm (STA). set spantree portpri port_string priority NOTE: Path cost (set spantree portcost) takes precedence over port priority. Syntax Description port_string priority...

  • Page 131: Show Spantree Portcost

    5.2.2.5 show spantree portcost Use this command to display cost values assigned to one or more Spanning Tree ports. show spantree portcost port_string Syntax Description port_string Command Defaults None. Command Mode Read-Only. Example This example shows how to display the port cost for front panel port 3. In this case, the 0 value indicates that the port has been set to use its default value when operating in a Spanning Tree: Matrix>show spantree portcost ge.0.3 Port cost = 0 for port ge.0.3.

  • Page 132: Set Spantree Portcost

    Reviewing and Setting Spanning Tree Port Parameters 5.2.2.6 set spantree portcost Use this command to assign a cost value to a Spanning Tree port. This parameter is used to determine the best path between Spanning Tree devices. Therefore, lower values should be assigned to ports attached to faster media, and higher values assigned to ports with slower media.
  • Page 133 Spanning Tree Configuration Reviewing and Setting Spanning Tree Port Parameters Example This example shows how to set port cost to 25 on front panel port 11: Matrix>set spantree portcost ge.0.11 25 Spanning tree port cost of 25 set for port ge.0.3. Matrix E1 Series (1G694-13) Configuration Guide 5-31...

  • Page 134: Show Spantree Adminedge

    Reviewing and Setting Spanning Tree Port Parameters 5.2.2.7 show spantree adminedge Use this command to display the edge port administrative status for a port. show spantree adminedge port_string Syntax Description port_string Command Defaults None. Command Mode Read-Only. Example This example shows how to display the edge port status for front panel port 3: Matrix>show spantree adminedge ge.0.3 admin edge = TRUE for port ge.0.3 5-32...

  • Page 135: Set Spantree Adminedge

    5.2.2.8 set spantree adminedge Use this command to set the edge port administrative status on a Spanning Tree port. set spantree adminedge port_string {true | false} Syntax Description port_string true | false Command Defaults None. Command Mode Read-Write. Example This example shows how to set front panel port 11 as an edge port: Matrix>set spantree adminedge ge.0.11 true Success setting admin edge to TRUE for port ge.0.3.

  • Page 136: Show Spantree Adminpoint

    Reviewing and Setting Spanning Tree Port Parameters 5.2.2.9 show spantree adminpoint Use this command to display the administrative point-to-point status of the LAN segment attached to a port. show spantree adminpoint port_string Syntax Description port_string Command Defaults None. Command Mode Read-Only.

  • Page 137: Set Spantree Adminpoint

    5.2.2.10 set spantree adminpoint Use this command to set the administrative point-to-point status of the LAN segment attached to a Spanning Tree port. set spantree adminpoint port_string {true | false | auto} Syntax Description port_string true | false | auto Command Defaults None.

  • Page 139: Vlan Configuration Summary

    This chapter describes the VLAN Configuration capabilities of the Matrix E1 1G694-13 device and how to use them to determine status, add, change, or delete VLANs, assign ports to those VLANs and configure the device for GVRP operation. The device can support one to 4095 802.1Q VLANs.

  • Page 140: Process Overview: 802.1Q Vlan Configuration

    VLAN list or untagged frames, and configure the GVRP function on the device. Preparing for VLAN Configuration A little forethought and planning is essential to a good VLAN implementation. Before attempting to configure a single switch for VLAN operation, consider the following: • How many VLANs will be required? •...

  • Page 141: Reviewing Existing Vlans

    VLAN CONFIGURATION COMMAND SET 6.2.1 Reviewing Existing VLANs Purpose To see a list of the current VLANs (dynamic and static) configured on the device, their VLAN type, and the ports on the VLAN egress list. The device uses the VLAN egress list to keep track of all VLANs that it will recognize.

  • Page 142: Show Vlan

    Reviewing Existing VLANs 6.2.1.1 show vlan Use this command to display information related to one or more VLAN(s) known to the device (static and dynamic). show vlan [vlan_id] Syntax Description vlan_id Command Defaults If vlan_id is not specified, information for all VLANs will be displayed. Command Mode Read-Only.
  • Page 143 This example shows how to display the information for VLAN 7 only. In this case, VLAN 7 has a VLAN name of green and it is enabled. Gigabit Ethernet front panel ports 5 through 7, 9, and 11 are in VLAN 7’s port egress list and are configured to transmit frames tagged as VLAN 7 frames. There are no VLAN 7 forbidden ports.

  • Page 144: Show Vlan Static

    Reviewing Existing VLANs 6.2.1.2 show vlan static Use this command to display all information related to one or more static VLAN(s) known to the device. Static VLANs are those VLANs that you have manually created using this command set, SNMP MIBs, or the WebView management application. show vlan static [vlan_id] Syntax Description vlan_id...

  • Page 145: Creating And Naming Static Vlans

    6.2.2 Creating and Naming Static VLANs Purpose To create a new static VLAN, or enable/disable the new or other existing static VLAN. Commands The commands needed to establish new or remove VLANs are listed below and described in the associated section as shown. •...

  • Page 146: Set Vlan

    Creating and Naming Static VLANs 6.2.2.1 set vlan Use this command to create a new static IEEE 802.1Q VLAN, or to enable or disable an existing VLAN. When a new VLAN is created, it is added to the list of VLANs that the device will recognize.

  • Page 147: Set Vlan Name

    Use this command to set the ASCII name for a new or existing VLAN. set vlan name vlan_id vlan_name NOTES: Each VLAN ID must be unique. If a duplicate VLAN ID is entered, the switch assumes that the administrator intends to modify the existing VLAN.

  • Page 148: Clear Vlan

    Creating and Naming Static VLANs 6.2.2.3 clear vlan Use this command to remove a static VLAN from the list of VLANs recognized by the device. clear vlan vlan_id Syntax Description vlan_id Command Defaults None. Command Mode Read-Write. Example This example shows how to remove a static VLAN 9 from the device’s VLAN list. Matrix>clear vlan 9 VLAN 9 removed.

  • Page 149: Clear Vlan Name

    6.2.2.4 clear vlan name Use this command to remove the name of a VLAN from the VLAN list. clear vlan name vlan_id Syntax Description vlan_id Command Defaults None. Command Mode Read-Write. Example This example shows how to clear the name for VLAN 9. Matrix>clear vlan name 9 The name for VLAN 9 cleared.

  • Page 150: Assigning Port Vlan Ids (Pvids) And Ingress Filtering

    Assigning Port VLAN IDs (PVIDs) and Ingress Filtering 6.2.3 Assigning Port VLAN IDs (PVIDs) and Ingress Filtering Purpose To assign default VLAN IDs to untagged frames on one or more ports. Using set port vlan you can, for example, assign ports 1, 5, 8, and 9 to VLAN 3. Untagged frames received on those ports will be assigned to VLAN 3.

  • Page 151: Show Port Vlan

    6.2.3.1 show port vlan Use this command to display which VLANs are on one or all port VLAN lists. show port vlan [port_string] Syntax Description port_string Command Defaults If port _string is not specified, all port VLAN information will be displayed. Command Mode Read-Only.

  • Page 152: Set Port Vlan

    Assigning Port VLAN IDs (PVIDs) and Ingress Filtering 6.2.3.2 set port vlan Use this command to configure the port VLAN identifier (vlan_id) for a single port or a range of ports. set port vlan port_string vlan_id Syntax Description port_string vlan_id Command Defaults None.

  • Page 153: Clear Port Vlan

    6.2.3.3 clear port vlan Use this command to reset the port’s 802.1Q port VLAN ID to the host VLAN ID 1. clear port vlan port_string Syntax Description port_string Command Defaults None. Command Mode Read-Write. Example This example shows how to reset the Gigabit Ethernet front panel ports 3 and 11 to a VLAN ID of 1 (default VLAN).

  • Page 154: Show Port Ingress Filter

    Assigning Port VLAN IDs (PVIDs) and Ingress Filtering 6.2.3.4 show port ingress filter Purpose To show all ports that are enabled for port ingress filtering to limit incoming frames according to a port VLAN egress list. If the port is not on the port VLAN egress list of the VLAN ID indicated in the incoming frame, then that frame is dropped and not forwarded.

  • Page 155: Set Port Ingress Filter

    6.2.3.5 set port ingress filter Purpose To limit the forwarding of received VLAN tagged frames on a port to the frames with VLAN IDs that match that port’s membership on port VLAN egress lists. When ingress filtering on a port is enabled, the VLAN ID of incoming frames on a received port are compared to the received ports on the egress list of that VLAN.

  • Page 156: Configuring The Vlan Egress List

    Configuring the VLAN Egress List 6.2.4 Configuring the VLAN Egress List Purpose To assign or remove ports on the VLAN egress list for the device. This determines which ports will transmit frames of a particular VLAN. For example, ports 1, 5, 9, 8 could be assigned to transmit frames with VLAN ID=5.

  • Page 157: Set Vlan Egress

    6.2.4.1 set vlan egress Use this command add or remove ports on the VLAN egress list for the device. This determines which ports will transmit frames for a particular VLAN. set vlan egress vlan_id port_string [untagged] Syntax Description vlan_id port_string untagged Command Defaults If untagged is not specified, the port will be added to the VLAN egress list as able...

  • Page 158: Clear Vlan Egress

    Configuring the VLAN Egress List 6.2.4.2 clear vlan egress Use this command to remove ports from a VLAN’s egress list. clear vlan egress vlan_id port_string Syntax Description vlan_id port_string Command Defaults None. Command Mode Read-Write. Example This example shows how to remove Gigabit Ethernet front panel port 5 from the egress list of VLAN 1.

  • Page 159: Setting The Host Vlan

    Setting the Host VLAN Purpose To assign the host port on the switch to a VLAN that only select devices are allowed to access. This secures the host port. This is useful, for example, in restricting the configuration of the devices in the system to a limited number of users.

  • Page 160: Show Host Vlan

    Setting the Host VLAN 6.2.5.1 show host vlan Use this command to display the current host VLAN. show host vlan Syntax Description None. Command Defaults None. Command Mode Read-Only. Example This example shows how to display the host VLAN. Matrix>show host vlan Host vlan is 7.

  • Page 161: Set Host Vlan

    VLAN can be specifically created, for example, for device management. This would allow a work station connected to the host VLAN to manage all ports on the switch, while making management secure by preventing access via ports assigned to other VLANs.

  • Page 162: Clear Host Vlan

    Setting the Host VLAN 6.2.5.3 clear host vlan Use this command to set the host VLAN back to the default setting of 1. clear host vlan Syntax Description None. Command Defaults None. Command Mode Read-Write. Example This example shows how to set the host VLAN to the default setting. Matrix>...

  • Page 163: Enabling/Disabling Gvrp (Garp Vlan Registration Protocol)

    6-1, Switch 4, port 1 is registered as being a member of VLAN Blue and then declares this fact out all its ports (2 and 3) to Switch 1 and Switch 2. These two switches register this in the Port Egress Lists of the ports (Switch 1, port 1 and Switch 2, port 1) that received the frames with the information.
  • Page 164 Enabling/Disabling GVRP (GARP VLAN Registration Protocol) Figure 6-1 Example of VLAN Propagation via GVRP Configuring a VLAN on an 802.1Q switch creates a static GVRP entry. The entry will always remain registered and will not time out. However, dynamic entries will time-out and their registrations are removed from the member list if the end station A is removed.

  • Page 165: Show Gvrp Configuration

    Commands The commands used to configure GVRP are listed below and described in the associated section as shown. • show gvrp configuration • set gvrp (Section 6.2.6.2) • set gvrp timer (Section 6.2.6.3) 6.2.6.1 show gvrp configuration Use this command to display GVRP configuration information, including timer values, GVRP global status, and GVRP port status.

  • Page 166: Set Gvrp

    IEEE 802.1Q documentation, which is not supplied with this device. 6.2.6.2 set gvrp Use this command to enable or disable GVRP globally in the switch or on a per-port basis. set gvrp {disable | enable} [port_string] Syntax Description...

  • Page 167: Set Gvrp Timer

    6.2.6.3 set gvrp timer Use this command to adjust the values of the join, leave, and leaveall timers. set gvrp timer {join | leave | leaveall} port string timer value NOTE: The setting of these timers are critical and should only be changed by personnel familiar with the 802.1Q standards documentation, which are not supplied with this device.

  • Page 169: Port Priority Configuration Summary

    Port Priority Configuration This chapter describes the Port Priority set of commands and how to use them. PORT PRIORITY CONFIGURATION SUMMARY This device supports Class of Service (CoS), which allows you to assign mission-critical data a higher priority through the device by delaying less critical traffic during periods of congestion. The higher priority traffic through the device is serviced first before lower priority traffic.

  • Page 170: Process Overview: Port Priority Configuration

    Process Overview: Port Priority Configuration 7.1.2 Process Overview: Port Priority Configuration Use the following steps as a guide in the port priority configuration process:. 1. Configuring Port Priority 2. Configuring Priority Queueing 3. Configuring Quality of Service (QoS) PORT PRIORITY CONFIGURATION COMMAND SET 7.2.1 Configuring Port Priority Purpose...

  • Page 171: Show Port Priority

    7.2.1.1 show port priority Use this command to view the 802.1D priority of a port. show port priority [port_string] Syntax Description port_string Command Defaults If port_string is not specified, port priority for all ports will be displayed. Command Mode Read-Only. Example This example shows how to display the port priority for the Gigabit Ethernet front panel port 11.

  • Page 172: Set Port Priority

    Configuring Port Priority 7.2.1.2 set port priority Use this command to set the priority (0 through 7) on each port. A port receiving a frame without priority information in its tag header is assigned a priority according to the priority setting on the port.

  • Page 173: Clear Port Priority

    7.2.1.3 clear port priority Use this command to reset the current 802.1D port priority setting to 0. This will cause all frames received without a priority value in its header to be set to priority 0. clear port priority port_string Syntax Description port_string Command Defaults...

  • Page 174: Configuring Priority To Transmit Queue Mapping

    Configuring Priority to Transmit Queue Mapping 7.2.2 Configuring Priority to Transmit Queue Mapping Purpose To display and set the current priority to transmit queue mapping of each port. Commands The commands used in configuring transmit port priority queues are listed below and described in the associated section.
  • Page 175 Examples This example shows how to display transmit queue mapping information. In this case, the frames shown with a priority of 0 or 3 are transmitted according to the transmit port priority queue of 1 (the second lowest transmit priority); frames with 1 or 2 priority, at the lowest transmit priority of 0; frames with 4 or 5 priority, at the second highest transmit priority of 2;...

  • Page 176: Set Priority Queue

    Configuring Priority to Transmit Queue Mapping 7.2.2.2 set priority queue Use this command to map 802.1p priorities to transmit queues. This enables you to change the port priority queue (0 -3, with 0 being the lowest priority queue) for each port priority. These settings are applied to all ports.

  • Page 177: Configuring Quality Of Service (Qos)

    7.2.3 Configuring Quality of Service (QoS) Purpose To configure one or more ports with the following Layer 2 switching features: • Four priority queues on each port. • Programmable scheduling according to weighted round-robin (in percentage of traffic per queue). Command Descriptions The commands to configure the Quality of Service are listed below and described in the associated section.

  • Page 178: Show Port Qos

    Configuring Quality of Service (QoS) 7.2.3.1 show port qos Use this command to display the current Quality of Service information of one or more ports. The current algorithm and associated queue settings are displayed for each port type. show port qos Syntax Description None.

  • Page 179: Set Port Qos Wrr

    7.2.3.2 set port qos wrr Use this command to set the weighted round robin transmission queue weights for a particular port type. set port qos wrr port_type que0_weight que1_weight que2_weight que3_weight Syntax Description port_type que0_weight que1_weight que2_weight que3_weight NOTE: The total percentage of transmit queue settings que0_weight through que3_weight must add up to 100%, otherwise the command is illegal.

  • Page 181: Multicast Filtering Configuration Summary

    This switch uses IGMP (Internet Group Management Protocol) to query for any attached hosts who want to receive a specific multicast service. The switch looks up the IP Multicast Group used for this service and adds any port that received a similar request to that group. It then propagates the service request on to any neighboring multicast switch/router to ensure that it will continue to receive the multicast service.

  • Page 182: Igmp Configuration Command Set

    8.2.1 Enabling / Disabling IGMP Purpose To display IGMP status and to enable or disable IGMP snooping on the switch. Commands The commands needed to display, enable and disable IGMP are listed below and described in the associated sections as shown.

  • Page 183: Show Igmp

    8.2.1.1 show igmp Use this command to display IGMP status. show igmp Syntax Description None. Command Defaults None. Command Mode Read-Only. Example This example shows how to display IGMP status. Matrix>show igmp IGMP Snooping is disabled. Enabling / Disabling IGMP Matrix E1 Series (1G694-13) Configuration Guide...

  • Page 184: Set Igmp

    Enabling / Disabling IGMP 8.2.1.2 set igmp Use this command to enable or disable IGMP snooping on the switch. This allows a host to inform the switch it wants to receive transmissions addressed to a specific multicast group. set igmp {enable | disable}...

  • Page 185: Setting Igmp Query Count And Report Delay

    IGMP group. Query count specifies the time in minutes that must elapse before the switch removes the port from an IGMP group. Report delay specifies the number of queries that must be missed before the IGMP report delay timer is started.

  • Page 186: Show Igmp Query Count

    Setting IGMP Query Count and Report Delay 8.2.2.1 show igmp query count Use this command to display the IGMP query count time in minutes. show igmp query count Syntax Description None. Command Defaults None. Command Mode Read-Write. Example This example shows how to display query count status. Matrix>show igmp query count IGMP query count is 5.

  • Page 187: Set Igmp Query Count

    8.2.2.2 set igmp query count Use this command to set the number of minutes that must elapse before the switch removes a port from an IGMP group. set igmp query count size Syntax Description size Command Defaults None. Command Mode Read-Write.

  • Page 188: Show Igmp Report Delay

    Setting IGMP Query Count and Report Delay 8.2.2.3 show igmp report delay Use this command to show IGMP report delay status. show igmp report delay Syntax Description None. Command Defaults None. Command Mode Read-Write. Example This example shows how to display IGMP report delay status. Matrix>show igmp report delay IGMP report delay is 5.

  • Page 189: Set Igmp Report Delay

    8.2.2.4 set igmp report delay Use this command to set the number of queries that must be missed before an IGMP report delay timer is started. set igmp report delay size Syntax Description size Command Defaults None. Command Mode Read-Write. Example This example shows how to set the IGMP report delay to 4 queries: Matrix>set igmp report delay 4...

  • Page 190: Reviewing Igmp Groups

    Reviewing IGMP Groups Purpose Use this command to display the status of IGMP groups on the switch. This includes the VLAN port configured to transmit IGMP multicast transmissions, its VLAN ID, and the IP addresses of the ports asking to receive those transmissions as part of the IGMP group.
  • Page 191 Table 8-1 provides details of the command output. Table 8-1 show igmp groups Output Details Field Vlan ID Multicast IP Type IGMP Port List This example shows the display when no IGMP groups have been configured on the device. Matrix>show igmp groups Multicast group list processed.

  • Page 192: About Ip Multicast Filtering

    A multicast-enabled switch device, can periodically ask their hosts if they want to receive multicast traffic. If there is more than one switch device on the LAN performing IP multicasting, one of these devices is elected “querier” and assumes the responsibility of querying the LAN for group members.

  • Page 193: Managing General Device Settings

    This chapter describes the Network Management set of commands and how to use them. PROCESS OVERVIEW: NETWORK MANAGEMENT Network Management tasks include the following: • Managing General Device Settings • Monitoring Network Events and Statistics • Managing Network Addresses and Routes NETWORK MANAGEMENT COMMAND SET 9.2.1 Managing General Device Settings...

  • Page 194: Clear Config

    Managing General Device Settings 9.2.1.1 clear config Use this command to clear the user-defined configuration parameters stored in NVRAM. This resets the device back to its factory default settings. For a list of default settings for this device, refer to Section 3.1.1.

  • Page 195: Reset

    9.2.1.2 reset Use this command to reset the device without losing any user-defined configuration settings. reset Syntax Description None. Command Defaults None. Command Mode Read-Write. Example This example shows how to use the reset command. Matrix>reset This command will reset the device. Do you want to continue (y/n) [n]? y Resetting device...

  • Page 196: Show Cdp

    Managing General Device Settings 9.2.1.3 show cdp Use this command to display the enable state of the CDP discovery protocol and message interval on one or more ports. show cdp [port_string] Syntax Description port_string Command Defaults If port_string is not specified, the CDP state for all ports will be displayed. Command Mode Read-Only.
  • Page 197 Table 9-1 provides a detailed explanation of the command output. Table 9-1 show cdp Output Details Output What It Displays... Port Port designation. For a detailed description of possible port_string values, refer to State Whether CDP is enabled, disabled or in auto mode. Freq Transmit frequency of CDP messages in seconds.

  • Page 198: Set Cdp

    Managing General Device Settings 9.2.1.4 set cdp Use this command to enable or disable the CDP discovery protocol globally or on one or more ports. set cdp {auto | disable | enable} [port_string] Syntax Description auto | disable | enable port_string Command Defaults If port_string is not specified, the CDP state for all ports will be set.

  • Page 199: Set Cdp Interval

    9.2.1.5 set cdp interval Use this command to set the frequency of the CDP discovery protocol. set cdp interval frequency port_string Syntax Description frequency port_string Command Defaults None. Command Mode Read-write. Example This example shows how to set the CDP interval frequency to 15 seconds on Gigabit Ethernet front panel port 8.

  • Page 200: Monitoring Network Events And Status

    Network Management Monitoring Network Events and Status 9.2.2 Monitoring Network Events and Status Purpose To display device events and command history, to set the size of the history buffer, and to display network and RMON statistics. Commands Commands to monitor network events and status are listed below and described in the associated section as shown.

  • Page 201: Show Eventlog

    9.2.2.1 show eventlog Use this command to display the system events for the device. show eventlog Syntax Description None. Command Defaults None. Command Mode Read-Only. Example This example shows how to use the show eventlog command. Matrix>show eventlog 07/01/2001 16:57:28- (Info 07/02/2001 08:29:13- (Info 07/04/2001 09:21:28- (Info Monitoring Network Events and Status...

  • Page 202: Clear Eventlog

    Monitoring Network Events and Status 9.2.2.2 clear eventlog Use this command to delete all entries from the system event log. clear eventlog Syntax Description None. Command Defaults None. Command Mode Read-Write. Example This example shows how to clear the event log. Matrix>clear eventlog Event Log cleared...>...

  • Page 203: History

    9.2.2.3 history Use this command to display the contents of the command history buffer. The command history buffer includes all the commands entered up to a maximum of 50, as specified in the set history command (Section 9.2.2.6). history Syntax Description None.

  • Page 204: Repeat

    Monitoring Network Events and Status 9.2.2.4 repeat Use this command to repeat a command shown in the command history buffer. repeat [cmd_num] [iterations] Syntax Description cmd_num iterations Command Defaults If no parameters are specified, the last command will be repeated. Command Mode Read-Write.

  • Page 205: Show History

    9.2.2.5 show history Use this command to display the size (in lines) of the history buffer. show history Syntax Description None. Command Defaults None. Command Mode Read-Only. Example This example shows how to display the size of the history buffer. Matrix>show history History buffer size: 3 Monitoring Network Events and Status...

  • Page 206: Set History

    Monitoring Network Events and Status 9.2.2.6 set history Use this command to set the size of the history buffer. set history size Syntax Description size Command Defaults None. Command Mode Read-Write. Example This example shows how to set the size of the command history buffer to 3 lines. Matrix>set history 3 History buffer size: 3 9-14...

  • Page 207: Show Netstat

    9.2.2.7 show netstat Use this command to display statistics for the device’s active network connections. show netstat [icmp | interface | ip | routes | stats | tcp | udp] Syntax Description icmp routes stats interface Command Defaults If no parameters are specified, show netstat will be executed as shown in the example below.
  • Page 208 Monitoring Network Events and Status Table 9-2 show netstat Output Details Output Proto Recv-Q Send-Q Local Address Foreign Address (state) 9-16 Matrix E1 Series (1G694-13) Configuration Guide What It Displays... Protocol Control Block designation. Type of protocol running on the connection. Number of queries received over the connection.

  • Page 209: Ping

    9.2.2.8 ping Use this command to send ICMP echo-request packets to another node on the network. ping {hostname [packet_count] | -s hostname} Syntax Description hostname packet_count Command Defaults The defaults for ping -s: • packet_size is 64 bytes The defaults for ping with no arguments: •...
  • Page 210 Monitoring Network Events and Status Examples This example shows how to ping IP address 10.1.10.1. Matrix>ping 10.1.10.1 Reply from 10.1.10.1 Reply from 10.1.10.1 Reply from 10.1.10.1 ------ PING 10.1.10.1: Statistics ------ 3 packets transmitted, 3 packets received, 0% packet loss This example shows how to ping IP address 10.1.10.1 with 10 packets.

  • Page 211: Show Rmon Stats

    9.2.2.9 show rmon stats Use this command to display RMON statistics for a port or range of ports. show rmon stats [port_string] Syntax Description port_string Command Defaults If port_string is not specified, RMON stats will be displayed for all ports. Command Mode Read-Only.
  • Page 212 Data source of the statistics being displayed. Total number of times that the RMON agent was forced to discard frames due to lack of available switch resources. This does not display the number of frames dropped, only the number of times the RMON agent was forced to discard frames.
  • Page 213 Table 9-3 show rmon stats Output Details (Continued) Output What It Displays... Fragments Number of received frames that are not the minimum number of bytes in length, or received frames that had a bad or missing Frame Check Sequence (FCS), were less than 64 bytes in length (excluding framing bits, but including FCS bytes) and had an invalid CRC.

  • Page 214: Show Users

    Monitoring Network Events and Status 9.2.2.10 show users Use this command to display information about the active console port or Telnet session(s) logged in to the device. show users Syntax Description None. Command Defaults None. Command Mode Read-Only. Example This example shows how to use the show users command. In this output, there is one telnet user at IP address 10.1.10.10.

  • Page 215: Disconnect

    9.2.2.11 disconnect Use this command to close an active console port or Telnet session. disconnect {A.B.C.D | console} Syntax Description A.B.C.D console Command Defaults None. Command Mode Read-Write. Examples This example shows how to close a Telnet session to host 10.1.10.10: Matrix>disconnect 10.1.10.10 Telnet session from 10.1.10.10 disconnected.

  • Page 216: Managing Network Addresses And Routes

    Managing Network Addresses and Routes 9.2.3 Managing Network Addresses and Routes Purpose To display, add or delete ARP table entries, to display, add or delete IP routing table addresses, and to display or delete MAC address information. Commands Commands to manage network addresses and routes are listed below and described in the associated section as shown.

  • Page 217: Show Arp

    9.2.3.1 show arp Use this command to display the device’s ARP table. show arp Syntax Description None. Command Defaults None. Command Mode Read-Only. Example This example shows how to display the ARP table: Matrix>show arp LINK LEVEL ARP TABLE destination gateway -------------------------------------------------------------------------- 10.1.0.1...

  • Page 218: Set Arp

    Managing Network Addresses and Routes 9.2.3.2 set arp Use this command to add mapping entries to the ARP table. set arp ip_addr hw_addr [temp] [pub] [trail] Syntax Description ip_addr hw_addr temp trail Command Defaults If temp is not specified, the ARP entry is added as a permanent entry. If pub is not specified, then the ARP entry is not published.

  • Page 219: Clear Arp

    9.2.3.3 clear arp Use this command to delete a specific entry or all entries from the ARP table. clear arp [hostname or A.B.C.D] Syntax Description hostname or A.B.C.D Command Defaults If hostname is not specified, all ARP entries will be cleared. Command Mode Read-Write.

  • Page 220: Show Ip Route

    Managing Network Addresses and Routes 9.2.3.4 show ip route Use this command to display IP routing table entries. show ip route Syntax Description None. Command Defaults None. Command Mode Read-Only. Example This example shows how to display the IP routing table. Matrix>show ip route destination gateway...

  • Page 221: Set Ip Route

    9.2.3.5 set ip route Use this command to add IP addresses or aliases to the IP routing table. set ip route gateway Syntax Description gateway Command Defaults None. Command Mode Read-Write. Example This example shows how to add a default route to the IP routing table. Matrix>set ip route 192.122.173.42 Route added.

  • Page 222: Clear Ip Route

    Managing Network Addresses and Routes 9.2.3.6 clear ip route Use this command to delete IP routing table entries. clear ip route gateway Syntax Description gateway Command Defaults None. Command Mode Read-Write. Example This example shows how to delete an IP routing table entry: Matrix>clear ip route 0.0.0.0 192.122.173.42 Route deleted.

  • Page 223: Show Mac

    9.2.3.7 show mac Use this command to display MAC addresses contained in the device’s source address table. show mac [address mac address] [fid vlan_Id ] [port port_string] [type {learned | self | mgmt}] Syntax Description address mac address vlan_id port port_string type Command Defaults...
  • Page 224 Managing Network Addresses and Routes Example This example shows how to display MAC address information. Matrix>show mac MAC Address -------------------------------------------------------- 00-00-1d-b5-47-a2 01-00-1d-00-00-00 00-e0-63-97-c9-fb 00-00-1d-b5-47-92 -------------------------------------------------------- Dynamic Address Counts : 2 9-32 Matrix E1 Series (1G694-13) Configuration Guide Port ge.0.12 00000000000001 host.0.1 Trunk1 Static Address Counts : 2...

  • Page 225: Clear Mac

    9.2.3.8 clear mac Use this command to clear dynamic MAC address information for the device. clear mac Syntax Description None. Command Defaults None. Command Mode Read-Write. Example This example shows how to clear dynamic MAC address information: Matrix>clear mac Address table cleared. Managing Network Addresses and Routes Matrix E1 Series (1G694-13) Configuration Guide 9-33...

  • Page 227: A.1 Overview

    Matrix E1 CLI Quick Reference Guide OVERVIEW This quick reference guide provides an alphabetical listing of CLI tasks, each with a brief description of command function and syntax. The section number included in each description links to the corresponding page in this guide where more detailed information about the command can be found.
  • Page 228 Clears the user-defined configuration parameters stored in NVRAM. For details, refer to Section clear config Displays counter statistics detailing traffic through the switch device and through all MIB2 network devices. For details, refer to Section 4.2.1.2. show port counters [port_string] [mib2 | switch] Disables one or more ports.
  • Page 229 CLI Task Command Function and Syntax event log (clear) Deletes all entries from the system event log. For details, refer to Section event log (show) Displays the system event log for the device. For details, refer to Section exit Exits a CLI session. For details, refer to flow control (set port) Enables or disables flow control for one or more ports.
  • Page 230 CLI Tasks, Commands and Syntax CLI Task history buffer size (show) history buffer size (set) IGMP (set) IGMP (show) IGMP groups (show) IGMP query count (set) IGMP query count (show) IGMP report delay (set) IGMP report delay (show) IP address (set) Matrix E1 Series (1G694-13) Configuration Guide Command Function and Syntax Displays the size (in lines) of the command history buffer.
  • Page 231 CLI Task Command Function and Syntax IP address (show) Displays the local host port IP address and the system mask. For details, refer to IP route (clear) Deletes IP routing table entries. For details, refer to IP route (set) Adds IP addresses to the device’s IP routing table. For details, refer to Section IP route (show) Displays the device’s IP routing table entries.
  • Page 232 CLI Tasks, Commands and Syntax CLI Task mirroring (show port) negotiation (set port) negotiation (show port) netstat (show) password (set) ping port ingress filter (set) port ingress filter (show) port priority (clear) Matrix E1 Series (1G694-13) Configuration Guide Command Function and Syntax Displays the source and target ports for mirroring, and whether mirroring is currently enabled or disabled for those ports.
  • Page 233 CLI Task Command Function and Syntax port priority (set) Sets the transmit queues (port priority queues, 0 through 7) according to strict 802.1 standards. For details, refer to port priority (show) Displays the port priority setting for one or more ports. For details, refer to priority queue (set) Maps 802.1p priorities to transmit queues.
  • Page 234 For details, refer to Section show rmon stats [port_string] Globally enables or disables the Spanning Tree algorithm on the switch. For details, refer to set spantree {disable | enable} Displays Spanning Tree information. For details, refer to Section 5.2.1.1.
  • Page 235 CLI Task Command Function and Syntax Spanning Tree hello (set) Sets the Spanning Tree hello time, This is the time interval (in seconds) the device will transmit BPDUs indicating it is active. For details, refer Enables or disables legacy (802.1D) path cost values. For details, Spanning Tree legacy path cost (set) refer to...
  • Page 236 CLI Tasks, Commands and Syntax CLI Task Spanning Tree port priority (set) Spanning Tree port priority (show) Spanning Tree port status (set) Spanning Tree priority (set) Spanning Tree real time message age (set) Spanning Tree real time message age (show) Spanning Tree transmit hold count (set) Spanning Tree transmit...
  • Page 237 CLI Task Command Function and Syntax Spanning Tree topology Displays the status of topology change trap suppression on Rapid change trap suppress Spanning Tree edge ports. For details, refer to (show) Spanning Tree version Sets the version of the Spanning Tree protocol to RSTP (Rapid (set) Spanning Tree Protocol) or to STP 802.1D-compatible.
  • Page 238 CLI Tasks, Commands and Syntax CLI Task terminal (set) time (set) time (show) trap (clear) trap (set) trap (show) trap (set port) trap (show port) trunk (clear) A-12 Matrix E1 Series (1G694-13) Configuration Guide Command Function and Syntax Sets the number of columns and rows of the display terminal connected to the console port of the device.
  • Page 239 CLI Task Command Function and Syntax trunk (set) Creates, enables or disables trunks on the device. For details, refer to Section trunk (show) Displays trunking information for the device. For details, refer to Section trunk port (clear) Removes a port from a trunk. For details, refer to trunk port (set) Adds one or more trunk ports to an existing trunk Section...
  • Page 240 CLI Task Command Function and Syntax VLAN (port, clear) Resets the port’s 802.1Q port VLAN ID to the host VLAN ID 1. For details, refer to VLAN (port, set) Sets the port VLAN identifier (vlan_id) for one or more ports. For details, refer to VLAN (port, show) Displays ports associated with a particular 802.1Q port VLAN ID.
  • Page 241 CLI Task Command Function and Syntax VLAN static (show) Displays all information related to one or more static VLANs. For details, refer to WebView (port, set) Sets a different TCP port through which to run WebView. For details, refer to Guide.
  • Page 243 Numerics 10-Gigabit Ethernet port introduction to 1-Gigabit Ethernet introduction to 802.1D 802.1w Adapter Wiring and Signal Assignments Auto-negotiation setting 4-14 Class of Service closing 3-33 getting help with syntax scrolling screens Command Defaults Command Line Interface. See also CLI Community Names setting 3-26 Cost...
  • Page 244 Network Management addresses and routes 9-24 general device settings monitoring network events and status Password setting the login 3-10 Port Mirroring 4-26 Port Priority configuring Port Status reviewing Port Trunking 4-29 Port(s) 10-Gigabit Ethernet 1-Gigabit Ethernet auto-negotiation and advertised ability enabling and disabling 4-11 flow control...

Table of Contents
