16 Accessories (optional)

Traverse 0.6m
For mounting the wind ve-
locity and wind direction
transmitter jointly onto a
mast.
Hanger
–FIRST CLASS- 1m
For the lateral mounting of
a wind velocity and wind di-
rection transmitter onto a
mast tube.
Lightning rod
For mounting the a/m trav-
erse or hanger.
Adaptor
For isolated mounting of
each wind transmitter and
wind direction transmitter
on the traverse
(4.3174.0.000).
Calibration without adjust-
ment:
Calibration without adjust-
ment:
Calibration with adjustment
and re-calibration
Calibration with adjustment
and re-calibration
Please contact us for other accessories such as cables, power supply units, masts, as well
as for additional mast- or system-constructions.
