Position Length Example
128 8 abcdefgh
136 1 *
137 2 xy
139 1 ETX
140 1 CR
141 1 LF
Pressure and acceleration sensors are thermally coupled.
Measured values
If the wind velocity exceeds the measured range specified by the calibration table, the stand-
ard curve will be used for the further calculation and the corresponding bit is set in the status
word.
© Adolf Thies GmbH & Co. KG · Hauptstraße 76 · 37083 Göttingen · Germany
Phone +49 551 79001-0 · Fax +49 551 79001-65 · info@thiesclima.com · www.thiesclima.com
Description
32-bit sensor status in hexadecimal representation
a: high nibble in high byte in HEX (Bit 31 ... 28)
b: low nibble in high byte in HEX (Bit 27 ... 24)
c: high nibble in byte 2 in HEX (Bit 23 ... 20)
d: low nibble in byte 2 in HEX (Bit 19 ... 16)
e: high nibble in byte 3 in HEX (Bit 15 ... 12)
f: low nibble in byte 3 in HEX (Bit 11 ... 8)
g: high nibble in low byte in HEX (Bit 7 ... 4)
h: low nibble in low byte in HEX (Bit 3 ... 0)
MODBUS-Register: 34811
Separation character ('*')
Exclusive or linked check sum in hexadecimal representation
x: high nibble check sum in HEX
y: low nibble check sum in HEX
End character (end of text)
Carriage Return
Line feed
Table 10: Measured Value Telegram
