Regis- Parameter name
ter ad-
dress
35025 Sensor status
1
(34811)
35027 Main loop run per 1s
35029 Operating time after reset
1
(34815)
35031
Inclination value
Angle between the Z-axis and the
vertical (34819)
35033
Inclination value
Angle between the X-axis and
the horizontal
(34821) 1
35035
Inclination value
Angle between the Y-axis and
the horizontal (34823)
35037 Frequency vibration measure-
ment, X-axis (34825)
35039 Acceleration vibration measure-
ment, X-axis
1
(34827)
35041 Frequency vibration measure-
ment, Y-axis
1
(34829)
35043 Acceleration vibration measure-
ment, Y-axis (34831)
35045 Frequency vibration measure-
ment, Z-axis (34833)
35047 Acceleration vibration measure-
ment, Z-axis (34835)
35049 Measured frequency
35051 Number of revolutions of the cup
star
35055 Operating hours
35057 Degree of turbulence
© Adolf Thies GmbH & Co. KG · Hauptstraße 76 · 37083 Göttingen · Germany
Phone +49 551 79001-0 · Fax +49 551 79001-65 · info@thiesclima.com · www.thiesclima.com
Unit
1/s
s
θ
°
1
ρ
°
Φ
°
1
Hz
1
mg
Hz
mg
1
Hz
1
mg
1
9
Hz
h
-
Multipli- Explanation
cator
105000=1050.00hP
a)
1 Value
(no decimal place,
bit coded, depend-
ing on sensor)
1 Value
(no decimal place,
e.g. 2550=2550 1/s)
1 Value
(no decimal place,
e.g. 255=255s)
10 Value / 10
(1 decimal place,
e.g. 240=24.0°)
10 Value / 10
(1 decimal place,
e.g. 240=24.0°)
10 Value / 10
(1 decimal place,
e.g. 240=24.0°)
10 Value / 10
(1 decimal place,
e.g. 240=24.0Hz)
1 Value
(no decimal place,
e.g. 24=24mg)
10 Value / 10
(1 decimal place,
e.g. 240=24.0Hz)
1 Value
(no decimal place,
e.g. 24=24mg)
10 Value / 10
(1 decimal place,
e.g.. 240=24.0Hz)
1 Value
(no decimal place,
e.g. 24=24mg)
10 Value
(1 decimal place,
e.g. 255=25.5Hz)
1 Value
(no decimal place,
e.g. 255=255)
1 Value
(no decimal place,
e.g. 255=255h)
100 Value
(2 decimal places
e.g. 255=2,55)
Data type
U32
U32
U32
S32
S32
S32
U32
U32
U32
U32
U32
U32
U32
U64
U32
U32
021814/03/21
Page 57 of 86
