Byte bit location
10
9
8
7
2
Byte 3
6
5
4
3
2
1
0
Table 7: Reading Time
1
: The first transmitted byte.
2
: The last transmitted byte.

11.3.5 Reading Calibration Tables

Reading out the MODBUS register of addresses 41000 to 41835 delivers the calibration
tables (41006-41075 standard characteristic line). Each table comprises 152 bytes, and is
coded as follows:
Byte
Byte 0 Target-Wind-Velocity-Address 1
Byte 1
Byte 2 Actual-Wind-Velocity-Address 1
Byte 3
Byte 4 Target-Wind-Velocity-Address 2
Byte 5
Byte 6 Actual-Wind-Velocity-Address 2
Byte 7
Byte 8 Target-Wind-Velocity-Address 3
Byte 9
Byte 10 Actual-Wind-Velocity-Address 3
Byte 11
Byte 12 Target-Wind-Velocity-Address 4
Byte 13
Byte 14 Actual-Wind-Velocity-Address 4
Byte 15
Byte 16 Target-Wind-Velocity-Address 5
Byte 17
Byte 18 Actual-Wind-Velocity-Address 5
Byte 19
Byte 20 Target-Wind-Velocity-Address 6
Byte 21
Byte 22 Actual-Wind-Velocity-Address 6
Byte 23
Byte 24 Target-Wind-Velocity-Address 7
Byte 25
© Adolf Thies GmbH & Co. KG · Hauptstraße 76 · 37083 Göttingen · Germany
Phone +49 551 79001-0 · Fax +49 551 79001-65 · info@thiesclima.com · www.thiesclima.com
time infor-
mation
Seconds
Parameter
(Resolution: 0.01m/s)
(Resolution: 0.01m/s)
(Resolution: 0.01m/s)
(Resolution: 0.01m/s)
(Resolution: 0.01m/s)
(Resolution: 0.01m/s)
(Resolution: 0.01m/s)
(Resolution: 0.01m/s)
(Resolution: 0.01m/s)
(Resolution: 0.01m/s)
(Resolution: 0.01m/s)
(Resolution: 0.01m/s)
(Resolution: 0.01m/s)
1
1
1
1
1
1
1
1
1
1
1
1
1
021814/03/21
