Regis- Parameter name
ter ad-
dress
Inclination angle θ Angle be-
36209
tween the Z-axis and the vertical
1
(34819)
Inclination angle ρ
36211
Angle between the X-axis and
the horizontal plane (34821)
Inclination Angle Φ Angle be-
36213
tween the Y-axis and the hori-
zontal plane (34823)
36215 Frequency vibration measure-
ment, x-axis (34825)
36217 Acceleration, x-axis (34827)
36219 Frequency vibration measure-
ment, y-axis (34829)
36221 Acceleration, y-axis (34831)
36223 Frequency vibration measure-
ment, z-axis (34833)
36225 Acceleration, z-axis (34835)
36227 Sensor status
1
(34811)
1
: The numbers in brackets designate the register addresses which represent the same s. For example,
the wind velocity is on address 30001 and on address 35001.
2
: Measuring values of the wind velocity (without compensation) acquired by means of standard characteristic curve.
3
: The measurement values of the wind speed detected by means of calibration characteristic.
4
: Average wind speed, based on the selected measured values (see command MS).
5
: The measured values of the wind speed (without compensation) recorded by means of the standard characteristic curve.
6.
Standard deviation of the wind speed, based on the selected measured values (see command MS).
7
: Minimum / maximum wind speed based on the selected measured values (see command MS).
8
: The air pressure compensated wind speed, based on the measured values recorded by means of the calibration curve.
9
: Info: It is the directly measured, uncorrected frequency. Independent of the command FO.
Note:
Due to the uninterrupted sequence of the measured val-
ues from address 35001, the MODBUS Master can read all
measured values with one request!
© Adolf Thies GmbH & Co. KG · Hauptstraße 76 · 37083 Göttingen · Germany
Phone +49 551 79001-0 · Fax +49 551 79001-65 · info@thiesclima.com · www.thiesclima.com
Unit Multipli-
cator
° 10
° 10
1
° 10
1
Hz 100
1
1 mg 1
Hz 100
1
1
mg 1
Hz 100
1
1
mg 1
1
Table 5 : MODBUS Input Register
Explanation Data type
Value / 10 S32
(1 decimal place,
e.g. 240=24.0°)
Value / 10 S32
(1 decimal place,
e.g. 240=24.0°)
Value / 10 S32
(1 decimal place,
e.g. 240=24.0°)
Value / 100 U32
(2 decimal place,
e.g 2400=24.00Hz)
Value U32
(no decimal place,
e.g. 24=24mg)
Value / 100 U32
(2 decimal place,
e.g. 2400=24.00Hz)
Value U32
(no decimal place,
e.g. 24=24mg)
Value U32
(no decimal place,
e.g. 24=24mg)
Value U32
(no decimal place,
e.g. 24=24mg)
value U32
(no decimal place,
bit coded, depend-
ence on the sensor)
