Pressure and acceleration sensors are thermally coupled.

12.5 Telegram 6

The wind sensor responds to the command "00TR6 \ r" with the measured value telegram.
The telegram structure is shown in the following table:
Position Length Sample
1 1 STX
2 2 xx
4 1 ;
5 5 xx.xx
10 1 ;
11 5 xx.xx
16 1 ;
17 5 xx.xx
22 1 ;
23 6 xxxx.x
29 1 ;
30 6 yxxx.x
36 1 ;
37 6 yxxx.x
43 1 ;
44 6 yxxx.x
50 1 ;
51 5 xxx.x
56 1 ;
57 4 xxxx
61 1 ;
62 5 xxx.x
© Adolf Thies GmbH & Co. KG · Hauptstraße 76 · 37083 Göttingen · Germany
Phone +49 551 79001-0 · Fax +49 551 79001-65 · info@thiesclima.com · www.thiesclima.com
Description
Start of text
Identification number (ID)
xx: 0...99
Separation marks (';')
Instantaneous value of the wind speed calculated with the
standard characteristic curve; Unit: m / s; Resolution:
0,01m/s.
Separation marks (';')
Instantaneous value of the wind speed calculated with the
current calibration table; Unit: m / s; Resolution: 0.01m / s.
If no calibration table is available, the calculated measured
value of the standard characteristic is output here.
Separation marks (';')
Instantaneous value of wind speed corrected as a function
of air pressure (wind speed calculated with the current cali-
bration table) Unit: m / s; Resolution: 0.01m / s.
Separation marks (';')
Absolute air pressure (unit: hPa)
xxxx.x: pressure value; Resolution: 0.1hPa
Separation marks (';')
θ
Tilt angle
Angle between the Z-axis and the vertical, unit: °
y: sign (+ or -)
xxx.x: angle; Resolution: 0,1°
Separation marks (';')
Tilt angle θ
Angle between the X-axis and the horizontal, unit: °
y: sign (+ or -)
xxx.x: angle; Resolution: 0.1 °
Separation marks (';')
Tilt angle Φ
Angle between the Y-axis and the horizontal, unit: °
y: sign (+ or -)
xxx.x: angle; Resolution: 0.1 °
Separation marks (';')
Frequency vibration measurement, x-axis (unit: Hz)
xxx.x: frequency; Resolution: 0.1Hz
Separation marks (';')
Acceleration vibration measurement, x-axis (unit: mg)
xxxx: acceleration; Resolution: 1mg
Separation marks (';')
Frequency vibration measurement, y-axis (unit: Hz)
xxx.x: frequency; Resolution: 0.1Hz
