11.1.2 Check Sum:

The check sum is the XOR link of all characters between <XTX> and the byte <*>.
The asterisk is the separation character of the check sum and is not contained in the check
sum.

11.1.3 Status Information:

Within the wind transmitter, the status word (32bit) is available which provides information
about the condition of the transmitter. The measured values are submitted to a plausibility
check and shown in the status word.
Bit number Function
Bit 0 Wind velocity jump
Bit 1 Calm
Bit 2 Measured value correc-
tion
Bit 3 Watchdog Reset
Bit 4 Filling level averaging
buffer < 100%
Bit 5...8 Calibration table
Bit 9 Vcc voltage
Bit 10 3V voltage
Bit 11 Pressure sensor
Bit 12 Acceleration sensor
Bit 13 EEPROM parameter
Bit 14 EEPROM parameter
Bit 15 New FW
Bit 16 -
© Adolf Thies GmbH & Co. KG · Hauptstraße 76 · 37083 Göttingen · Germany
Phone +49 551 79001-0 · Fax +49 551 79001-65 · info@thiesclima.com · www.thiesclima.com
Description
= 1 if the difference between the wind velocity between
2 subsequent measured values in the second interval
exceeds 10m/s.
= 1 if the wind velocity remains for at least 3 hours at
0m/s without interruption.
= 1 if the measured wind velocity is outside the defined ta-
ble range.
= 1 after a reset conditioned by the watchdog.
= 1, averaging buffer has not yet filled completely.
After a restart of the wind transmitter, this bit remains
set until the averaging buffer has been filled completely.
Bits 5 to 8 show the calibration table used for the calcula-
tion of the wind velocity.
0000 : Standard curve
0001 : Calibration table 1
0010 : Calibration table 2
0011 : Calibration table 3
0100 : Calibration table 4
0101 : Calibration table 5
0110 : Calibration table 6
0111 : Calibration table 7
1000 : Calibration table 8
1001 : Calibration table 9
1010 : Calibration table 10
=1, Vcc voltage outside admissible range.
=1, 3V voltage outside admissible range.
=1, measured values from the pressure sensor are faulty.
=1, measured values from the acceleration sensor are
faulty.
=1, internal EEPROM parameters invalid.
=1, internal EEPROM parameters contain the standard
values.
=1, last restart was done with new firmware.
Internal use.
