12.2 Telegram 2

The wind transmitter responds with the measured value telegram 2 to the command
"00TR2\r". The table below shows the telegram structure:
Position Length Example
1 1 STX
2 2 xx
4 1 ;
5 5 xx.xx
10 1 ;
11 5 xx.xx
16 1 ;
17 5 xx.xx
22 1 ;
23 5 xx.xx
28 1 ;
29 5 xxx.x
34 1 ;
35 5 yxx.x
40 1 ;
41 5 xxxx.x
46 1 ;
47 6 xxxx.x
53 1 ;
54 6 xxxx.x
60 1 ;
61 6 xxxx.x
67 1 ;
68 8 abcdefgh
© Adolf Thies GmbH & Co. KG · Hauptstraße 76 · 37083 Göttingen · Germany
Phone +49 551 79001-0 · Fax +49 551 79001-65 · info@thiesclima.com · www.thiesclima.com
Description
Start character (start of text).
Identification number (ID)
xx: 0..99
Separation character (';')
Instantaneous value of the wind velocity, calculated with
the
current calibration table; unit: m/s; resolution: 0.01m/s.
Separation character (';')
Instantaneous value of the wind velocity, calculated with
the standard curve; unit: m/s; resolution: 0.01m/s.
Separation character (';')
Instantaneous value of the wind velocity, corrected de-
pending on the air pressure (wind velocity calculated with
the current calibration table
0.01m/s.
Separation character (';')
reserved
Separation character (';')
reserved
Separation character (';')
Housing interior temperature of the wind transmitter (unit:
°C)
y: Sign (+ or -)
xx.x: Temperature value; resolution: 0.1°C
Separation character (';')
Temperature of pressure- and acceleration sensor (unit:
°C)
y: Sign (+ or -)
xx.x: Temperature value; resolution: 0.1°C
Separation character (';')
Absolute air pressure (unit: hPa)
xxxx.x: Pressure value; resolution: 0.1hPa
Separation character (';')
Absolute air pressure, corrected depending on the wind
velocity (unit: hPa)
xxxx.x: Pressure value; resolution: 0.1hPa
Separation character (';')
Relative air pressure (unit: hPa)
xxxx.x: Pressure value; resolution: 0.1hPa
Separation character (';')
32Bit Sensor status in hexadecimal representation
a: high nibble in high byte in HEX (Bit 31 ... 28)
b: low nibble in high byte in HEX (Bit 27 ... 24)
c: high nibble in byte 2 in HEX (Bit 23 ... 20)
d: low nibble in byte 2 in HEX (Bit 19 ... 16)
1
) unit: m/s; resolution:
