Position Length Sample
34 1 ETX
35 1 CR
36 1 LF
Pressure and acceleration sensors are thermally coupled.

12.4 Telegram 5

The wind sensor responds to the command "00TR5 \ r" with the measured value telegram.
The telegram structure is shown in the following table:
Position Length Sample
1 1 STX
2 2 xx
4 1 ;
5 5 xx.xx
10 1 ;
11 5 xx.xx
16 1 ;
17 5 xx.xx
22 1 ;
23 6 xxxx.x
29 1 ;
30 8 abcdefgh
38 1 *
39 2 xy
41 1 ETX
42 1 CR
43 1 LF
© Adolf Thies GmbH & Co. KG · Hauptstraße 76 · 37083 Göttingen · Germany
Phone +49 551 79001-0 · Fax +49 551 79001-65 · info@thiesclima.com · www.thiesclima.com
Description
y: low nibble checksum in HEX
End character (end of text)
Carriage return (Carriage Return)
Line feed
Table 12: Value-Telegram 4
Description
Start of text
Identification number (ID)
xx: 0...99
Separation marks (';')
Instantaneous value of the wind speed calculated with the
standard characteristic curve; Unit: m / s; Resolution:
0.01m / s.
Separation marks (';')
Instantaneous value of the wind speed calculated with the
current calibration table; Unit: m / s; Resolution: 0.01m / s.
If no calibration table is available, the calculated measured
value of the standard characteristic is output here.
Separation marks (';')
Instantaneous value of wind speed corrected as a function
of air pressure (wind speed calculated with the current cali-
bration table) Unit: m / s; Resolution: 0.01m / s.
Separation marks (';')
Absolute air pressure (unit: hPa)
xxxx.x: pressure value; Resolution: 0.1hPa
Separation marks (';')
32Bit Sensor status in hexadecimal representation
a: high nibble im high byte in HEX (Bit 31 ... 28)
b: low nibble im high byte in HEX (Bit 27 ... 24)
c: high nibble im byte 2 in HEX (Bit 23 ... 20)
d: low nibble im byte 2 in HEX (Bit 19 ... 16)
e: high nibble im byte 3 in HEX (Bit 15 ... 12)
f: low nibble im byte 3 in HEX (Bit 11 ... 8)
g: high nibble im low byte in HEX (Bit 7 ... 4)
h: low nibble im low byte in HEX (Bit 3 ... 0)
Separation marks ('*')
Exclusive or linked checksum in hexadecimal notation
x: high nibble checksum in HEX
y: low nibble checksum in HEX
End of text
Carriage Return
Line feed
Table 13: Measured value telegram 5
