Bit number Function
Bit 17...19 Source mean value calcu-
lation
Bit 20...31 -

11.2 Commands and Description

The following table lists the available commands and the corresponding password for read-
ing and writing:
Command Initial
value
Factory
setting
Command BR 96
Command BT 0
Command CI 0/1
Command CK 137
Command FB 1
Command FO 4
Command HP 500
Command HT 0
Command ID 0/1
Command KX 0
Command KY 0
Command MI 10
Command MS 1
Command OH -
Command RC -
Command RS -
Command SF 0
1
The device version 4.3352.x0.400 is delivered with 0 (THIES- Interpreter), the version 4.3352.x0.401
is delivered with 1 (MODBUS RTU).
2
The device version 4.3352.x0.400 is delivered with ID0, the version 4.3352.x0.401 is delivered with
ID1. If the sensor includes an additional label with the ID, the ID of the label is valid.
3
For reading the entries of the calibration table please see chapter 9.3.3 Calibration table in the
MODBUS-RTU Interpreter.
