Thies CLIMA First Class Advanced X Instructions For Use Manual page 70

Position Length Example
53 1 ;
54 5 yxx.x
59 1 ;
60 6 xxxx.x
66 1 ;
67 6 xxxx.x
73 1 ;
74 6 yxxx.x
80 1 ;
81 6 yxxx.x
87 1 ;
88 6 yxxx.x
94 1 ;
95 5 xxx.x
100 1 ;
101 4 xxxx
105 1 ;
106 5 xxx.x
111 1 ;
112 4 xxxx
116 1 ;
117 5 xxx.x
122 1 ;
123 4 xxxx
127 1 ;
© Adolf Thies GmbH & Co. KG · Hauptstraße 76 · 37083 Göttingen · Germany
Phone +49 551 79001-0 · Fax +49 551 79001-65 · info@thiesclima.com · www.thiesclima.com
Description
Separation character (';')
Temperature of pressure and acceleration sensor
(unit: °C)
y: Sign (+ or -)
xx.x: Temperature value; resolution: 0.1°C; MODBUS-Register:
35059
Separation character (';')
Absolute air pressure (unit: hPa)
xxxx.x: Pressure value; resolution: 0.1hPa; MODBUS-Register:
30801
Separation character (';')
Relative air pressure (unit: hPa)
xxxx.x: Pressure value; resolution: 0.1hPa; MODBUS-Register:
30803
Separation character (';')
θ
Inclination value
Angle between the Z-axis and the vertical, unit: °
y: Sign (+ or -)
xxx.x: Angle; resolution: 0.1; MODBUS-Register: 34819
Separation character (';')
ρ
Inclination value
Angle between the X-axis and the horizontal, unit: °
y: Sign (+ or -)
xxx.x: Angle; resolution: 0.1°; MODBUS-Register: 34821
Separation character (';')
Φ
Inclination value
Angle between the Y-axis and the horizontal, unit: °
y: Sign (+ or -)
xxx.x: Angle; resolution: 0.1°; MODBUS-Register: 34823
Separation character (';')
Frequency vibration measurement, X-axis (unit: Hz)
xxx.x: Frequency; resolution: 0.1Hz; MODBUS-Register: 34825
Separation character (';')
Acceleration vibration measurement, X-axis xxxx: Amplitude;
resolution: 1mg; MODBUS-Register: 34827
Separation character (';')
Frequency vibration measurement, Y-axis (unit: Hz)
xxx.x: Frequency; resolution: 0.1Hz; MODBUS-Register: 34829
Separation character (';')
Acceleration vibration measurement, Y-axis
xxxx: Amplitude; resolution: 1mg; MODBUS-Register: 34831
Separation character (';')
Frequency vibration measurement, Z-axis (unit: Hz)
xxx.x: Frequency; resolution: 0.1Hz; MODBUS-Register: 34833
Separation character (';')
Acceleration vibration measurement, Z-axis xxxx: acceleration;
resolution: 1mg; MODBUS-Register: 34835
Separation character (';')
021814/03/21
Page 70 of 86
