Position Length Example
76 1 *
77 2 xy
79 1 ETX
80 1 CR
81 1 LF
Pressure and acceleration sensors are thermally coupled.
: If there is no calibration table or the "UC" parameter is 0, the calculated measured value of
1)
the standard characteristic is used here.

12.3 Telegram 4

The wind sensor responds to the command "00TR4 \ r" with the measured value telegram.
The telegram structure is shown in the following table:
Position Length Sample
1 1 STX
2 2 xx
4 1 ;
5 5 xx.xx
10 1 ;
11 5 xx.xx
16 1 ;
17 5 xx.xx
22 1 ;
23 8 abcdefg
h
31 1 *
32 2 xy
© Adolf Thies GmbH & Co. KG · Hauptstraße 76 · 37083 Göttingen · Germany
Phone +49 551 79001-0 · Fax +49 551 79001-65 · info@thiesclima.com · www.thiesclima.com
Description
e: high nibble in byte 3 in HEX (Bit 15 ... 12)
f: low nibble in byte 3 in HEX (Bit 11 ... 8)
g: high nibble in low byte in HEX (Bit 7 ... 4)
h: low nibble in low byte in HEX (Bit 3 ... 0)
Separation character (';')
Exclusive or linked check sum in hexadecimal representa-
tion
x: high nibble check sum in HEX
y: low nibble check sum in HEX
End character (end of text)
Carriage Return
Line feed
Table 11 : Measured Value Telegram 2
Description
Start of text
Identification number (ID)
xx: 0..99
Separation marks (';')
Instantaneous value of the wind speed, calculated with the stand-
ard curve; Unit: m / s; Resolution: 0.01m / s.
Separation marks (';')
Instantaneous value of the wind speed, calculated with the current
calibration table; Unit: m / s; Resolution: 0.01m / s. If no calibration
table is available, the calculated measured value of the standard
characteristic is output here.
Separation marks (';')
Instantaneous value of wind speed corrected as a function of air
pressure (wind speed calculated with the current calibration table)
Unit: m / s; Resolution: 0.01m / s.
Separation marks (';')
32Bit Sensor status in hexadecimal representation
a: high nibble im high byte in HEX (Bit 31 ... 28)
b: low nibble im high byte in HEX (Bit 27 ... 24)
c: high nibble im byte 2 in HEX (Bit 23 ... 20)
d: low nibble im byte 2 in HEX (Bit 19 ... 16)
e: high nibble im byte 3 in HEX (Bit 15 ... 12)
f: low nibble im byte 3 in HEX (Bit 11 ... 8)
g: high nibble im low byte in HEX (Bit 7 ... 4)
h: low nibble im low byte in HEX (Bit 3 ... 0)
Separation marks ('*')
Exclusive or linked checksum in hexadecimal representation
x: high nibble checksum in HEX
