In order to avoid an accidental parameter setting, some commands (see command list) are
protected by a password. This password must be sent prior to the actual command.
Example: Change of the baud rate
00KY234<CR> enable commands of the user level
00BR4<CR> set baud rate to 4800
!00BR00004<CR> baud rate set to 4800
The wind transmitter supports 3 different password levels.
•
User level (password: "234").
•
Calibration value level.
•
Administrator level.
Attention:
The commands protected by a password are enabled until
one of the following conditions is fulfilled:
- switching of the supply voltage
- the command 00KY0<CR> is sent
- no new command is sent for at least 120s

11.1.1 Telegram Formats

Data is output on request by the command TR. The following telegrams can be selected:
•
Measured value telegram (parameter = 1).
•
Measured value telegram 2 (parameter = 2).
•
Measured value telegram 4 (parameter =4).
•
Measured value telegram 5 (parameter =5).
•
Measured value telegram 6 (parameter =6).
•
Measured value memory telegram (parameter = 30).
The calculation of the check sum, the composition of the status word and the control / sepa-
ration characters used in the telegrams are listed below:
Control characters:
CR – Carriage Return (13
LF – Line Feed (10 ; 0x0A)
dec
STX – Start of Text (2
dec
ETX – End of Text (3
dec
Separation characters:
Separation character between the single measured values in the string is the semicolon ';'.
The check sum separation character is the asterisk '*'.
© Adolf Thies GmbH & Co. KG · Hauptstraße 76 · 37083 Göttingen · Germany
Phone +49 551 79001-0 · Fax +49 551 79001-65 · info@thiesclima.com · www.thiesclima.com
; 0x0D)
dec
; 0x02)
; 0x03)
