Wind transmitter
Table of Contents

Advertisement

Characteristics
Wind load
Heater
Electric supply for
electronic
Electric supply for Housing
heater
Type of connection
Mounting
Dimensions
Weight
Type of protection
Material
Housing, vane
Mast-adaptor

14 FAQ - Frequently Asked Questions

For this product we have provided a FAQ - Frequently Asked Questions collection for our
customers on the homepage.
Link:
https://www.thiesclima.com/db/dnl/4.3352.x0.40x_FAQ_en.pdf
© Adolf Thies GmbH & Co. KG · Hauptstraße 76 · 37083 Göttingen · Germany
Phone +49 551 79001-0 · Fax +49 551 79001-65 · info@thiesclima.com · www.thiesclima.com
Description
Approx. 100 N @ 75m/s
Surface temperature of the housing neck >0°C
at 20m/s to -10°C air temperature, at 1 0m/s to -20°C
Use of the Thies icing standard 012002 on the housing neck
Heater controlled with temperature sensor.
Voltage:
3.7 ... 42V DC (galvanically separated from the
housing)
Current:
40mA typ.
100mA max. (with heating pressure sensor on)
approx. 3.3mA in power saving mode SM1, HT0
Voltage:
24V AC/DC, 45 ... 65Hz
Open circuit voltage:
max. 30V AC, max. 42V DC
Wattage:
25W
Proportional control, control temperature: 5°C,
Heater can be enabled disabled via interface,
galvanically separated to the housing and the measured value
logging
8-pin connector for shielded conductor in shaft
(see connection diagram)
Mounting on mast
≤ 34mm
Outer diameter
≥ 22mm
Inner diameter
Note:
mounting on mast is possible with separate
adapter (option).
see dimensional drawing
approx. 0.5kg
IP 55 (DIN 40050)
Aluminum (AlMgSi1)
Stainless steel V4A (1.4571)
021814/03/21
Page 80 of 86
