Thies CLIMA First Class Advanced X Instructions For Use Manual page 77

Position Length Example
32 5 xxx.x
37 1 ;
38 5 xxx.x
43 1 ;
44 5 xxx.x
49 1 ;
50 5 xxx.x
55 1 ;
56 5 xxx.x
61 1 ;
62 5 xxx.x
67 1 ;
68 5 xxx.x
73 1 ;
74 5 xxx.x
79 1 ;
80 5 xxx.x
85 1 ;
86 5 xxx.x
91 1 ;
92 5 xxx.x
97 1 ;
98 5 xxx.x
103 1 ;
104 1 *
105 2 xy
107 1 ETX
108 1 CR
109 1 LF
© Adolf Thies GmbH & Co. KG · Hauptstraße 76 · 37083 Göttingen · Germany
Phone +49 551 79001-0 · Fax +49 551 79001-65 · info@thiesclima.com · www.thiesclima.com
Description
Measured value (4); unit: m/s; resolution: 0.1m/s
Separation character (';')
Measured value (5); unit: m/s; resolution: 0.1m/s
Separation character (';')
Measured value (6); unit: m/s; resolution: 0.1m/s
Separation character (';')
Measured value (7); unit: m/s; resolution: 0.1m/s
Separation character (';')
Measured value (8); unit: m/s; resolution: 0.1m/s
Separation character (';')
Measured value (9); unit: m/s; resolution: 0.1m/s
Separation character (';')
Measured value (10); unit: m/s; resolution: 0.1m/s
Separation character (';')
Measured value (11); unit: m/s; resolution: 0.1m/s
Separation character (';')
Measured value (12); unit: m/s; resolution: 0.1m/s
Separation character (';')
Measured value (13); unit: m/s; resolution: 0.1m/s
Separation character (';')
Measured value (14); unit: m/s; resolution: 0.1m/s
Separation character (';')
Measured value (15); unit: m/s; resolution: 0.1m/s
Separation character (';')
Separation character ('*')
Exclusive or linked check sum in hexadecimal representation
x: high nibble check sum in HEX
y: low nibble check sum in HEX
End character (end of text)
Carriage Return
Line feed
Table 15 : Measured Value Memory Telegram
021814/03/21
Page 77 of 86
