Regis- Parameter name
ter ad-
dress
30803 Relative air pressure (35023)
34811 32-bit sensor status in hexadeci-
mal representation
a: high nibble in high byte in HEX
(Bit 31 ... 28)
b: low nibble in high byte in HEX
(Bit 27 ... 24)
c: high nibble in byte 2 in HEX
(Bit 23 ... 20)
d: low nibble in byte 2 in HEX (Bit
19 ... 16)
e: high nibble in byte 3 in HEX
(Bit 15 ... 12)
f: low nibble in byte 3 in HEX (Bit
11 ... 8)
g: high nibble in low byte in HEX
(Bit 7 ... 4)
h: low nibble in low byte in HEX
(Bit 3 ... 0)
Sensor status (35025)
34813 Main loop run per 1s (35027)
34815 Operating time (35029)
34819
Inclination value
Angle between the Z-axis and the
vertical (35031)
34821
Inclination value
Angle between the X-axis and
the horizontal
1
(35033)
34823
Inclination value
Angle between the Y-axis and
the horizontal (35035)
34825 Frequency vibration measure-
ment, X-axis (35037)
34827 Acceleration vibration measure-
ment, X-axis
1
(35039)
34829 Frequency vibration measure-
ment, Y-axis (35041)
34831 Acceleration vibration measure-
ment, Y-axis (35043)
© Adolf Thies GmbH & Co. KG · Hauptstraße 76 · 37083 Göttingen · Germany
Phone +49 551 79001-0 · Fax +49 551 79001-65 · info@thiesclima.com · www.thiesclima.com
Unit
1
hPa
1
1 1/s
1
s
θ
°
1
ρ
°
Φ
°
1
Hz
1
mg
Hz
1
mg
1
Multipli- Explanation
cator
100 Value / 100
(2 decimal places
e.g.
105000=1050.00hP
a)
1 Value
(no decimal place,
bit coded, depend-
ing on sensor)
1 Value
(no decimal place,
e.g. 2550=2550 1/s)
1 Value
(no decimal place,
e.g. 255=255s)
10 Value / 10
(1 decimal place,
e.g. 240=24.0°)
10 Value / 10
(1 decimal place,
e.g. 240=24.0°)
10 Value / 10
(1 decimal place,
e.g. 240=24.0°)
100 Value / 100
(2 decimal places
e.g. 2400=24.00Hz)
1 Value
(no decimal place,
e.g. 24=24mg)
100 Value / 100
(2 decimal places
e.g. 2400=24.00Hz)
1 Value
Data type
U32
U32
U32
U32
S32
S32
S32
U32
U32
U32
U32
