5.3 ADVANCED SETTINGS
Event masks have two possible settings, YES or NO. If an action (e.g. the trip of a protection function) is set as
YES, when the trip takes place an event will be generated. If it is set as NO, no event will be generated.
5.3.8.1 EVENT MASK FOR MIWII1000
EVENT MASKS
EVENT MASKS
40 CIRCLE 1 Pickup/Drop out
40 CIRCLE 2 Pickup/Drop out
32_1 Alarm Pickup/Drop out
32_1 Trip Pickup/Drop out
32_2 Alarm Pickup/Drop out
32_2 Trip Pickup/Drop out
32_3 Alarm Pickup/Drop out
32_3 Trip Pickup/Drop out
40 Disabled by digital input
32_1 Disabled by digital input
32_2 Disabled by digital input
32_3 Disabled by digital input
Trip Disabled by digital input
40 CIRCLE 1 Function trip
5
40 CIRCLE 2 Function trip
32_1 alarm
32_1 trip
32_2 alarm
32_2 trip
32_3 alarm
32_3 trip
General trip
Unit 40 voltage inhibition activation/deactivation
Fuse Failure unit pickup/dropout
32_1 unit block
32_2 unit block
32_3 unit block
40 unit block
Protection status: in service/out of service
Digital output 1 active/non active
Digital output 2 active/non active
Digital output 3 active/non active
Digital output 4 active/non active
Digital input 1 active/non active
Digital input 2 active/non active
Settings change disabled by digital input
Trip operation by digital input
Trip operation by command
Auxiliary digital output latch reset
Close Breaker
Settings group change
Oscillo trigger by digital input
Oscillo trigger by command
5-8
5.3.8 EVENTS MASKS(ONLY ENERVISTA MII SETUP)
ENERVISTA MII SETUP
EVENT MASKS
40 Circle 1 Pickup
40 Circle 2 Pickup
32_1 Alarm Pickup
32_1 Pickup
32_2 Alarm Pickup
32_2 Pickup
32_3 Alarm Pickup
32_3 Pickup
40 Disabled (by DI)
32_1 disabled (by DI)
32_2 disabled (by DI)
32_3 disabled (by DI)
Trip disabled by DI
40 Circle 1 Trip
40 Circle 2 Trip
32_1 Alarm
32_1 Trip
32_2 Alarm
32_2 Trip
32_3 Alarm
32_3 Trip
General Trip
40 Voltage inhibit
Fuse Failure
32_1 Blocked
32_2 Blocked
32_3 Blocked
40 Blocked
Protection status
Output 1
Output 2
Output 3
Output 4
Digital input 1
Digital input 2
Sett. change disabled
Trip operation by input
Trip operation by command
Reset latch aux
Close Breaker operation
Settings group change
Oscillo trigg by DI
Oscillo trigg by comm.
MIWII Directional Power Protection System
5 SETTINGS
DEFAULT
RANGE
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
YES
Y/N
