2.7 EVENTS
Table 2–3: MIWII2000 LIST OF EVENTS
MIWII 2000 EVENT LIST
1
2
3
4
5
2
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
2-12
Pickup / Dropout of unit 32_1 alarm
Pickup / Dropout of unit 32_1 trip
Pickup / Dropout of unit 32_2 alarm
Pickup / Dropout of unit 32_2 trip
Pickup / Dropout of unit 32_3 alarm
Pickup / Dropout of unit 32_3 trip
Pickup / Dropout of unit 32_4 alarm
Pickup / Dropout of unit 32_4 trip
Unit 32_1 inhibition by digital input
Unit 32_2 inhibition by digital input
Unit 32_3 inhibition by digital input
Unit 32_4 inhibition by digital input
Trip inhibition by digital input
32_1 alarm
32_1 trip
32_2 alarm
32_2 trip
32_3 alarm
32_3 trip
32_4 alarm
32_4 trip
General trip
Unit 32_1 block
Unit 32_2 block
Unit 32_3 block
Unit 32_4 block
Protection activation / deactivation (READY)
Auxiliary Output 1 activation / deactivation
Auxiliary Output 2 activation / deactivation
Auxiliary Output 3 activation / deactivation
Auxiliary Output 4 activation / deactivation
Auxiliary Input 1 activation / deactivation
Auxiliary Input 2 activation / deactivation
Setting change inhibition by D.I. activation / deactivation
Trip command by D.I. activation
Trip command by communications activation
Reset Latch. Aux.
Close Breaker
Table Change
Oscillography trigger by D.I.
Oscillography trigger by communications
52B Open/closed by D.I.
Breaker status
Settings change
EEprom failure
User settings activation/deactivation
