9.14 USER SETTINGS
9.14.2.1 GENERAL ADVANCED
GENERAL ADVANCED
Identification
Settings Group
Trip Min Time
9.14.2.2 FUNCTION 40 (MIWII1000)
FUNCTION 40
Enable 40
Volt Superv 40
Voltage Level 40
Trip Enable 40 1
Diam Circle 40 1
Offs Circle 40 1
Delay Circl 40 1
Trip Enable 40 2
Diam Circle 40 2
Offs Circle 40 2
Delay Circl 40 2
9.14.2.3 FUNCTION 32 1
FUNCTION 32 1
Enable 32 1
Trip Enable 32 1
Power 32 1
Type 32 1
Direction 32 1
Alarm Level 32 1
Alarm Delay 32 1
Trip Level 32 1
Trip Delay 32 1
Block 32 1
9
9-20
ENERVISTA MII
SETUP
ADV. GENERAL
SETTINGS
IDENTIFICATION
Settings Group
Trip Min Time
ENERVISTA MII
SETUP
40 T2
40 Enable T2
Enable Voltage
Supervision T2
Voltage Level T2
Enable Circle 1 Trip T2 Trip Enable 40 1
Circle 1 Diameter T2
Circle 1 Offset T2
Circle 1 Trip Delay T2
Enable Circle 2 Trip T2 Trip Enable 40 2
Circle 2 Diameter T2
Circle 2 Offset T2
Circle 2 Trip Delay T2
ENERVISTA MII SETUP HMI
32_1 FUNCTION T2 FUNCTION 32 1
32_1 Enable T2 Enable 32 1
32_1 Trip T2 Trip Enable 32 1
32_1 Power Type T2 Power 32 1
32_1 Minimum/Maximum T2 Type 32 1
32_1 Forward/Reverse T2 Direction 32 1
32_1 Alarm Level T2 Alarm Level 32 1
32_1 Alarm Delay T2 Alarm Delay 32 1
32_1 Trip Level T2 Trip Level 32 1
32_1 Trip Delay T2 Trip Delay 32 1
Block 32_1 From Online T2 Block 32 1
MIWII Directional Power Protection System
HMI SETTING
GENERAL
ADVANCED
---
Settings Group
Trip Min Time
HMI SETTING
FUNCTION 40
Enable 40
Volt Superv 40
Voltage Level 40
Diam Circle 40 1
Offs Circle 40 1
Delay Circl 40 1
Diam Circle 40 2
Offs Circle 40 2
Delay Circl 40 2
SETTING
9 RELAY COMMISSIONING

9.14.2 ADVANCED SETTINGS

RANGE STEP
Text NA
1-2 NA
50-300 ms 1 ms
RANGE STEP
YES/NO NA
YES/NO NA
0.70 to 1.00 Vn 0.01
YES/NO NA
1 to 300 Ohm 0.1
1 to 180 Ohm 0.1
0.1 to 10 s 0.1
YES/NO NA
1 to 300 Ohm 0.1
1 to 180 Ohm 0.1
0.2 to 10 s 0.1
RANGE
YES/NO
YES/NO
ACTIVE / REACTIVE / APPARENT
MINIMUM / MAXIMUM
FORWARD / REVERSE
0.01 - 1.5
0.2 – 120 s
0.01 – 1.50
0.2 – 120 s
0 - 5000
GEK-113308
STEP
NA
NA
NA
NA
0.01
0.01
0.1
0.01
0.1
1
