The ModBus Format (Intel/Motorola) setting, in General Settings, provides with different ways to access and/or modify
the relay information
Differences between selecting the Intel or Motorola setting are explained in the following table:
ModBus Map Addressing
Data presentation
Operations
GEK-113308
INTEL
One byte at a time
High Byte – Low Byte
Selection + Confirmation
MIWII Directional Power Protection System
B.1 MODBUS FORMAT
MOTOROLA
One word at a time
Low Byte – High Byte
Confirmation
