2.8 OSCILLOGRAPHY
2
2-14
OSCILLOGRAPHY RECORD MIWII1000
ANALOG CHANNELS
1
Ia
Phase A current channel
2
VI
VI voltage channel
3
VII
VII voltage channel
4
VIII
VIII voltage channel
DIGITAL CHANNELS
1
Pickup of unit 40 CIRCLE 1
2
Pickup of unit 40 CIRCLE 2
3
Pickup of 32_1 alarm
4
Pickup of 32_1 trip
5
Pickup of 32_2 alarm
6
Pickup of 32_2 trip
7
Pickup of 32_3 alarm
8
Pickup of 32_3 trip
9
General Pickup
10
Unit 40 inhibition by digital input
11
Unit 32_1 inhibition by digital input
12
Unit 32_2inhibition by digital input
13
Unit 32_3 inhibition by digital input
14
Trip inhibition by digital input
15
Trip of unit 40 CIRCLE 1
16
Trip of unit 40 CIRCLE 2
17
32_1 alarm
18
32_1 trip
19
32_2 alarm
20
32_2 trip
21
32_3 alarm
22
32_3 trip
23
General trip
24
TRIP
25
ALARM, Relay in service
26
Auxiliary Output 1
27
Auxiliary Output 2
28
Auxiliary Output 3
29
Auxiliary Output 4
30
Auxiliary Input 1
31
Auxiliary Input 2
32
Breaker 52b
33
Breaker closed
34
Table Change
35
40 Voltage inhibit
36
Fuse Failure
37
E2prom failure
38
User settings
OTHER DATA
1
Date and Time
2
Relay model
Table 2–4: OSCILLOGRAPHY RECORD MIWII1000
MIWII Directional Power Protection System
2 PRODUCT DESCRIPTION
GEK-113308
