9.11 LOSS OF FIELD UNIT (40) MIWII1000

9.11LOSS OF FIELD UNIT (40) MIWII1000
Set the unit as follows:
Ensure that the input configured as 52B (breaker status) is not active, indicating open breaker. If it was, the unit would be
disabled and the relay would not operate.
With the V APP setting entered, the relay calculates the impedance as VI/Ia.
The voltage supervision is enabled, at a level of 70% of the rated voltage:
Supervision V = 70% of Vn = 0.7 x 11000 / 100 √3 = 44 V
9
9-12
GROUP: GENERAL
SETTING
STA
VT RATIO
RATED VOLTAGE
FRQ
V APP
GROUP: 40
ENABLE 40
V SUP 40
V 40
TRIP 40 1
DIAM1 40
OFFS1 40
TIME1 40
TRIP 40 2
DIAM2 40
OFFS2 40
TIME2 40
MIWII Directional Power Protection System
9 RELAY COMMISSIONING
VALUE
RDY
100
11000
50 Hz
1P WYE
Y
Y
0.7
Y
16 OHM
2 OHM
0.5
Y
40 OHM
2 OHM
1
