5.2 MAIN SETTINGS

5.2MAIN SETTINGS

PRODUCT SETUP

Relay Status
Current CT ratio
Voltage VT ratio
Nominal Power
Nominal Voltage
Generator Power Factor
Frequency
ModBus Format
V App
HMI Password
Comm Password
Slave Address
Communications Speed
FUNCTION 40
Enable 40
5
Volt Superv 40
Voltage Level 40
Trip Enable 40 1
Diam Circle 40 1
Offs Circle 40 1
Delay Circl 40 1
Trip Enable 40 2
Diam Circle 40 2
Offs Circle 40 2
Circle 2 timer
5-2
ENERVISTA MII SETUP HMI
PRODUCT SETUP PRODUCT SETUP
Relay Operation Relay Operation
CT Ratio Current CT Ratio
VT Ratio Voltage VT ratio
Rated MVA Nominal Power
Rated Voltage Nominal Voltage
Power Factor Power Fact
Frequency Frequency
--- ModBus Format
VT Connection Type V App
--- HMI Password
--- Comm Password
--- Slave Address
--- Comm Baud Rate
ENERVISTA MII SETUP HMI
40 FUNCTION 40
40 Enable Enable 40
Enable Voltage
Volt Superv 40
Supervision
Voltage Level Voltage Level 40
Enable Circle 1 Trip Trip Enable 40 1
Circle 1 Diameter Diam Circle 40 1
Circle 1 Offset Offs Circle 40 1
Circle 1 Trip Delay Delay Circl 40 1
Enable Circle 1 Trip Trip Enable 40 2
Circle 2 Diameter Diam Circle 40 2
Circle 2 Offset Offs Circle 40 2
Circle 2 Trip Delay TIME2 40
MIWII Directional Power Protection System
5.2.1 PRODUCT SETUP
DEFAULT RANGE
DISABLE READY / DISABLE
1 1-4000
1000 1.00-4000.00
30.00 0.05-1000.00MVA
11000 100-30000 V
0.9 0.05-0.99
60 Hz 50/60 Hz
Intel Intel/Motorola
3P WYE/3P DELTA/
3P WYE
1P WYE/1P DELTA
1 1-9999
1 1 – 255
1 1 – 255
0.3, 0.6, 1.2, 2.4, 4.8,
9.6
9.6, 19.2

5.2.2 FUNCTION 40 (MIWII1000)

DEFAULT RANGE
NO YES/NO
YES YES/NO
0.70 Vn 0.70 to 1.00 Vn
NO YES/NO
25 Ohm 1 to 300 Ohm
2.5 Ohm 1 to 180 Ohm
5 s 0.1 to 10 s
NO YES/NO
25 Ohm 1 to 300 Ohm
2.5 Ohm 1 to 280 Ohm
5 s 0.2 to 20 s
5 SETTINGS
STEP
NA
1
0.01
0.01
1
0.01
NA
NA
NA
1
1
1
NA
STEP
NA
NA
0.01
NA
0.1
0.1
0.1
NA
0.1
0.1
0.1
GEK-113308
