6 I/0 CONFIGURATION

6.2OUTPUTS AND LEDS CONFIGURATION

MIWII incorporates 6 outputs and 6 LED indicators. 4 of the outputs and LED indicators are user configurable, and can
only be programmed using ENERVISTA MII SETUP software (SETPOINT – RELAY CONFIGURATION). The first two
LEDs are fixed for READY (System ready) and TRIP. The fixed outputs are programmed for ALARM (System alarm) and
TRIP.
The TRIP LED activates when the TRIP contact closes.
The READY LED turns on when all the following conditions are fulfilled:
• The relay status is READY
• At least one of the protection functions of the active table is enabled
• The trip of at least one of the enabled functions is also enabled.
The default configuration for outputs is as follows:
FOR MIWII1000:
OUTPUT
1
2
3
4
FOR MIWII2000:
OUPUTS
1
2
3
4
The default LED configuration is as follows:
FOR MIWII1000:
LED
1
2
3
4
FOR MIWII2000:
LED
1
2
3
4
GEK-113308
CONFIGURATION
40 Trip
32_1 Trip
32_2 Trip
32_ 3 Trip
CONFIGURATION
32_1Trip
32_2 Trip
32_3 Trip
32_4 Trip
CONFIGURATION
40trip
32_1trip
32_2 trip
32_2 trip
CONFIGURATION
32_1Trip
32_2 Trip
32_3 Trip
32_4 Trip
MIWII Directional Power Protection System
6.2 OUTPUTS AND LEDS CONFIGURATION

6.2.1 DESCRIPTION OF OUTPUTS AND LEDS

MEMORY
No
No
No
No
MEMORY
No
No
No
No
MEMORY
Yes
Yes
Yes
Yes
MEMORY
Yes
Yes
Yes
Yes
6
6-5
