GE Multilin MIWII Instruction Manual page 5

6. I/0 CONFIGURATION
7. LOGIC CONFIGURATION
8. KEYPAD AND DISPLAY
9. RELAY COMMISSIONING
GEK-113308
TABLE OF CONTENTS
5.4 TIME SYNCHRONIZATION
6.1 INPUT CONFIGURATION
6.1.1 DESCRIPTION OF INPUTS .............................................................................. 6-1
6.1.2 INPUT ELEMENTS ............................................................................................ 6-4
6.2 OUTPUTS AND LEDS CONFIGURATION
6.2.1 DESCRIPTION OF OUTPUTS AND LEDS ....................................................... 6-5
6.2.2 OUTPUT AND LED ELEMENTS ....................................................................... 6-7
7.1 LOGIC DESCRIPTION
7.2 LOGIC ELEMENTS
8.1 DESCRIPTION
8.2 FACEPLATE KEYPAD
8.3 ALPHANUMERIC DISPLAY AND LEDS
8.3.1 DISPLAY ............................................................................................................ 8-3
8.3.2 LEDS.................................................................................................................. 8-4
8.4 OPERATIONS
8.4.1 ONE KEY OPERATION AND LAST TRIP DATA............................................... 8-5
8.4.2 HMI PASSWORD............................................................................................... 8-6
8.5 MENU TREE
8.5.1 MENU TREE FOR MIWII 1000 MODELS .......................................................... 8-7
8.5.2 MENU TREE FOR MIWII 2000 MODELS ........................................................ 8-13
9.1 VISUAL INSPECTION
9.2 COMMENTS ON THE TEST EQUIPMENT
9.3 WIRING AND NECESSARY EQUIPMENT
9.4 TARGET LEDS
9.5 POWER SUPPLY TEST
9.6 COMMUNICATIONS
9.7 RELAY SETTING
9.8 CONTACT INPUTS
9.9 CONTACT OUTPUTS
9.10 RELAY METERING
9.10.1 CURRENT AND VOLTAGE METERING ......................................................... 9-11
9.11 LOSS OF FIELD UNIT (40) MIWII1000
9.11.1 TEST OF UNITS 40 CIRCLE 1 AND 40 CIRCLE 2 ......................................... 9-13
9.11.2 TEST OF THE VOLTAGE BLOCK................................................................... 9-13
9.12 POWER UNITS (32)
9.12.1 FUNCTION 32_1.............................................................................................. 9-14
9.12.2 FUNCTION 32_2.............................................................................................. 9-14
9.12.3 FUNCTION 32_3.............................................................................................. 9-15
9.13 TIME SYNCHRONIZATION
9.14 USER SETTINGS
9.14.1 MAIN SETTINGS ............................................................................................. 9-17
9.14.2 ADVANCED SETTINGS .................................................................................. 9-20
MIWII Directional Power Protection System III
