7 LOGIC CONFIGURATION

7.2LOGIC ELEMENTS

The list of elements that can be assigned in the configurable logic is divided into the following groups:
FOR MIWII1000:
GROUP
CONFIGURATION
TRIP 1
TRIP 2
PICKUP 1
PICKUP 2
TRIP READY 1
TRIP READY 2
MISCELLANEOUS 2
MASK ED 1
MASK ED 2
INPUTS / OUTPUTS
GEK-113308
NO DEFINITION OUTPUT OR LED NOT ASSIGNED
Logic 1 Output signal from logic 1
Logic 2 Output signal from logic 2
Logic 3 Output signal from logic 3
Logic 4 Output signal from logic 4
40 Circle 1 Trip Trip of Function 40 Circle 1
40 Circle 2 Trip Trip of Function 40 Circle 2
32_1 Alarm Alarm of Function 32_1
32_1 Trip Trip of Function 32_1
32_2 Alarm Alarm of Function 32_2
32_2 Trip Trip of Function 32_2
32_3 Alarm Alarm of Function 32_3
32_3 Trip Trip of Function 32_3
General Trip General trip
40 Circle 1 Pickup Pickup of Function 40 Circle 1
40 Circle 2 Pickup Pickup of Function 40 Circle 2
32_1 Alarm Pickup Pickup Alarm of Function 32_1
32_1 Pickup Pickup of Function 32_1
32_2 Alarm Pickup Pickup Alarm of Function 32_2
32_2 Pickup Pickup of Function 32_2
32_3 Alarm Pickup Pickup Alarm of Function 32_3
32_3 Pickup Pickup of Function 32_3
General Pickup General pickup
40 Circle 1 Virtual Trip Virtual trip of Function 40 Circle 1
40 Circle 2 Virtual Trip Virtual trip of Function 40 Circle 2
32_1 Virtual Trip Virtual trip of Function 32_1
32_2 Virtual Trip Virtual trip of Function 32_2
32_3 Virtual Trip Virtual trip of Function 32_3
General Virtual Trip General Virtual Trip
40 Blocked Function 40 Blocked
32_1 Blocked Function 32_1 Blocked
32_2 Blocked Function 32_2 Blocked
32_3 Blocked Function 32_3 Blocked
40 Disable (by DI) Function 40 Disabled by Digital Input
32_1 Disable (by DI) Function 32_1 Disabled by Digital Input
32_2 Disable (by DI) Function 32_2 Disabled by Digital Input
32_3 Disable (by DI) Function 32_3 Disabled by Digital Input
DI all functions disable Digital Input all functions disable
Output 1 Digital output 1
Output 2 Digital output 2
Output 3 Digital output 3
Output 4 Digital output 4
Input 1 Digital input 1
Input 2 Digital input 2
