2 PRODUCT DESCRIPTION
OSCILLOGRAPHY RECORD MIWII 2000
ANALOG CHANNELS
1
2
3
4
DIGITAL CHANNELS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
OTHER DATA
Date and time
Model
GEK-113308
Ia
VI
32_1 Alarm Pickup
32_1 Pickup
32_2 Alarm Pickup
32_2 Pickup
32_3 Alarm Pickup
32_3 Pickup
32_4 Alarm Pickup
32_4 Pickup
General Pickup
32_1 Disable (by di)
32_2 Disable (by di)
32_3 Disable (by di)
32_4 Disable (by di)
Trip disabled (by di)
32_1 Alarm
32_1 Trip
32_2 Alarm
32_2 Trip
32_3 Alarm
32_3 Trip
32_4 Alarm
32_4 Trip
General trip
TRIP
ALARM
Output1
Output2
Output3
Output4
Input1
Input2
Breaker 52b
Breaker Closed
Table change
E2PROM failure
User Settings
Table 2–5: OSCILLOGRAPHY RECORD MIWII2000
MIWII Directional Power Protection System
Phase A current channel
VI voltage channel
32_1 pickup (alarm level)
32_1 pickup (trip level)
32_2 pickup (alarm level)
32_2 pickup (trip level)
32_3 pickup (alarm level)
32_3 pickup (trip level)
32_4 pickup (alarm level)
32_4 pickup (trip level)
General Pickup (any Protection unit)
32_1 disable by digital input
32_2 disable by digital input
32_3 disable by digital input
32_4 disable by digital input
Trip Disabled by digital input
32_1 unit alarm
32_1 unit trip
32_2 unit alarm
32_2 unit trip
32_3 unit alarm
32_3 unit trip
32_4 unit alarm
32_4 unit trip
General trip (any Protection unit)
TRIP
Relay in service
Auxiliary output 1
Auxiliary output 2
Auxiliary output 3
Auxiliary output 4
Digital Input 1
Digital Input 2
Breaker contact 52B input
Breaker closed (in the MIWII this
signal equals the 52B status)
Table change
EEPROM failure
User has modified the default settings
