4 COMMUNICATIONS
4.6 COMMUNICATION
4.6.1.3 COMMUNICATION OPTIMIZATION
COMMUNICATIONS OPTIMIZATION box allows the user to enter values to control device response to communication
attempts. Changing these parameters can improve communication, although it is recommended not to make changes to
the default values if it is not required.
Figure 4–22: COMMUNICATION OPTIMIZATION
4.6.1.4 PRINT SCREEN
When the Print Screen button is pressed, a new window appears asking if the user wants to capture the entire screen or
4
only the active window (the one with all the communication parameters). Yes means capturing the whole screen and No
means capturing only the communications window.
Then a new window appears allowing to view the captured screen, to save the captured file in BMP or JPG format, or to
print it (the print dialog window will appear so as the user can select which printer to use and enter the appropriate printer
settings).
Figure 4–23: PRINT SCREEN
GEK-113308
MIWII Directional Power Protection System
4-21
