Advanced Settings; General Advanced; Function 40 T2 (Miwii1000); Function 32 1 T2 (Miwii1000/Miwii2000) - GE Multilin MIWII Instruction Manual

5 SETTINGS

5.3ADVANCED SETTINGS

GENERAL ADVANCED

Identification
Settings Group
Trip Min Time
NOTE ABOUT THE TRIP MIN TIME SETTING:
This setting indicates the time during which the tripping contact will remain closed as a minimum in case of fault. If the
fault persists for a longer time than the set value, the tripping contact will remain closed and will be opened immediately
after the fault is cleared, while if the fault is shorter than the set time, the relay will maintain the contact closed for this set
time.
ENERVISTA MII SETUP
FUNCTION 40 T2 40 T2
Enable 40 T2 40 Enable T2
Volt Superv 40 T2 Enable Voltage Supervision T2 Volt Superv 40
Voltage Level 40 T2 Voltage Level T2
Trip Enable 40 1 T2 Enable Circle 1 Trip T2
Diam Circle 40 1 T2 Circle 1 Diameter T2
Offs Circle 40 1 T2 Circle 1 Offset T2
Delay Circl 40 1 T2 Circle 1 Trip Delay T2
Trip Enable 40 2 T2 Enable Circle 2 Trip T2
Diam Circle 40 2 T2 Circle 2 Diameter T2
Offs Circle 40 2 T2 Circle 2 Offset T2
Delay Circle40 2 T2 Circle 2 Trip Delay T2
ENERVISTA MII SETUP
FUNCTION 32 1 T2 32_1 FUNCTION T2
Enable 32 1 T2 32_1 Enable T2
Trip Enable 32 1 T2 32_1 Trip T2
Power 32 1 T2 32_1 Power Type T2
Type 32 1 T2 32_1 Minimum/Maximum T2 Type 32 1
Direction 32 1 T2 32_1 Forward/Reverse T2
Alarm Level 32 1 T2 32_1 Alarm Level T2
Alarm Delay 32 1 T2 32_1 Alarm Delay T2
Trip Level 32 1 T2 32_1 Trip Level T2
Trip Delay 32 1 T2 32_1 Trip Delay T2
Block 32 1 T2 Block 32_1 From Online T2 Block 32 1
GEK-113308
ENERVISTA MII SETUP HMI
ADV. GENERAL GENERAL
SETTINGS ADVANCED
IDENTIFICATION ---
Settings Group Settings Group
Trip Min Time Trip Min Time
HMI
FUNCTION 40
Enable 40
Voltage Level 40
Trip Enable 40 1
Diam Circle 40 1
Offs Circle 40 1
Delay Circl 40 1
Trip Enable 40 2
Diam Circle 40 2
Offs Circle 40 2
Delay Circl 40 2
HMI
FUNCTION 32 1
Enable 32 1
Trip Enable 32 1
Power 32 1
Direction 32 1
Alarm Level 32 1
Alarm Delay 32 1
Trip Level 32 1
Trip Delay 32 1
MIWII Directional Power Protection System
5.3 ADVANCED SETTINGS
5.3.1 GENERAL ADVANCED
DEFAULT RANGE
MIWII Text
1 1-2
200 ms 50-300 ms

5.3.2 FUNCTION 40 T2 (MIWII1000)

DEFAULT RANGE
NO YES/NO
YES YES/NO
0.70 0.70 to 1.00 Vn
NO YES/NO
25 Ohm 1 to 300 Ohm
2.5 Ohm 1 to 180 Ohm
5 s 0.1 to 10 s
NO YES/NO
25 Ohm 1 to 300 Ohm
2.5 Ohm 1 to 180 Ohm
5 s 0.2 to 10 s

5.3.3 FUNCTION 32 1 T2 (MIWII1000/MIWII2000)

DEFAULT RANGE
NO YES/NO
NO YES/NO
ACTIVE ACTIVE / REACTIVE / APPARENT NA
MINIMUM MINIMUM / MAXIMUM
FORWARD FORWARD / REVERSE
0.05 0.01 - 1.5
10 s 0.2 – 120 s
0.05 0.01 – 1.50
10 s 0.2 – 120 s
1s 0 - 5000
STEP
NA
NA
1 ms
STEP
NA
NA
0.01
NA
0.1
5
0.1
0.1
NA
0.1
0.1
0.1
STEP
NA
NA
NA
0.01
0.01
0.1
0.01
0.1
1
5-5
