9.12 POWER UNITS (32)

9.12POWER UNITS (32)
For all the steps included in this test, the relay general setting must be the following ones:
For this unit, the relay must trip due to an excess of positive active power
According to these values the theoretical trip value is:
0.05 x NOMINAL S x POWER FACT x 1/CT X 1/VT = 45 W
• Apply 0 W and check that the relay does not trip (0V or 0A).
• Increase the power until producing a trip, and check that the operation range does not exceed in ±6% the theoretical
value.
• Apply 100 W and check that the operating time does not exceed from 60 ms
For this unit, the relay must trip due to a low positive active power
9
9-14
GENERAL SETTINGS
RELAY STATUS
CT RATIO
VT RATIO
NOMINAL S
NOMINAL V
POWER FACT
FREQUENCY
V App 3P
NAME VALUE
32_1 Enable
32_1 Trip
32_1 Power Type
32_1 Minimum/Maximum
32_1 Forward/Reverse
32_1 Alarm Level
32_1 Alarm Delay
32_1 Trip Level
32_1 Trip Delay
Block 32_1 From Online
NAME
32_2 Enable
32_2 Trip
32_2 Power Type
32_2 Minimum/Maximum
32_2 Forward/Reverse
32_2 Alarm Level
32_2 Alarm Delay
32_2 Trip Level
32_2 Trip Delay
Block 32_2 From Online
MIWII Directional Power Protection System
9 RELAY COMMISSIONING
ENABLE
100
100
10 MVA
11000 V
0.9
50Hz
WYE
Yes
Yes
ACTIVE
MAXIMUM
FORWARD
.05 pu
10 s
.05 pu
0 s
1 s
VALUE
Yes
Yes
ACTIVE
MINIMUM
FORWARD
.05 pu
10 s
.05 pu
0 s
1 s

9.12.1 FUNCTION 32_1

9.12.2 FUNCTION 32_2

GEK-113308
