Control Knobs - Intellijel Metropolix Manual

CONTROL KNOBS
(SECTION 10)
Metropolix was conceived and designed as a 'playable' sequencer — allowing sequences to evolve
and mutate with the simplest of gestures. The two programmable CTRL knobs further enhance
these capabilities — allowing you to control any two Metropolix parameters with a twist of the wrist.
Each CTRL knob has its own CTRL SETTINGS screen (accessed by pushing the CTRL knob's
corresponding black button), from which you select the parameter and track(s) that you want the
knob to control.
There are two main parameters visible on each of the CTRL SETTINGS screen:
CTRL <n> PARAM : Selects the parameter you wish to control with the corresponding CTRL knob
( CTRL 1 or CTRL 2 ). Choices are:
None Pitch Offset ±
Accum ± Pitch Post ±
Accum Inv ± Pitch Pre ±
Clock Div In Play Order
Direction ± Prob ±
Gate Length Pulse Count ±
Gate Scale Pulse Div
Octave ± Pulses Len
Ratchet ±
Bipolar parameters are indicated by a '±' symbol following the parameter name.
Bipolar parameters output the sequencer's programmed value when a CTRL
knob is pointing straight up (noon position). Turning the knob counterclockwise
Metropolix Manual
Root
Skip Invert ±
Slide Amount
Slider Invert ±
Slider Range
Stages Len
Stages Offset
Swing
Trk Out Swap ±
115
