TYPE (CV TYPE)
The eighth Stage button in ALT Mode is used to set whether the TRK 1 or TRK 2 CV Lane acts as a
gate CV or as a continuous voltage source.
Pressing it opens the CV TYPE screen, which contains a single parameter:
CV TYPE : Selects whether a track's CV lane is a gate pattern or a continuous control voltage,
as determined by the two choices:
CV Value : When set to this value, each stage in a track's CV Lane (accessed by
pressing EDIT + CV ) can be set to a voltage between ±5V, along with an option for
determining how that voltage is reached (step vs ramp), as described in
in the manual.
Gate Toggle : When set to this value, each stage in a track's CV Lane (accessed
by pressing EDIT + CV ) can be set to transmit either a high (+5V) gate or a low
(0V) gate, as described in
In Use:
1. Press the button ( TRK 1 or TRK 2 ) corresponding to the track whose CV Type you wish to
define.
2. Press the ALT button followed by the TYPE (Stage 8) button to open the CV TYPE screen.
3. Turn the encoder to select between 'CV Value' and 'Gate Toggle'.
The change is applied immediately, and you will now be able to edit the CV Lane (accessed by
pressing EDIT followed by the CV button).
To reset CV TYPE back to its default setting, long-press the encoder.
CV , earlier in the manual.
