INTRODUCTION

OUTLINE DIMENSIONS

B1
or
B 2
A1
or
A 2
49 ft-5 1/4 in
(15,07m)
23 ft-3 3/4 in
(7,11 m)
21 ft -6 3/4 in
(6,57 m)
1-103
1-4
8 ft -6 1/4 in
6 ft -3 1/4 in
(2,60 m)
(1,91 m)
Outline Dimensions Continued on Next Page
Published 12-05-17, Control # 032-23
A1=100 ft (30,48 m) Mast = 118 ft, 11 in (36,25 m)
B1=100 ft (30,48 m) Mast = 123 ft, 1 in (37,51 m)
A 2=140 ft (42,67 m) Mast = 157 ft, 3 in (47,93 m)
B 2=140 ft (42,67 m) Mast = 163 ft, 1 in (49,70 m)
5 ft -10 in
(1,78 m)
5 ft
(1,52 m)
18000 OPERATOR MANUAL
17 ft-10 1/4 in
11 ft-4 1/2 in
(5,44 m)
(3,46 m)
16 ft-5 in
6 ft-9 1/2 in
(5,00 m)
(2,07 m)
FIGURE 1-4
