IDENTIFICATION AND LOCATION OF
COMPONENTS
28
27
25
24
22
23
21
19
18
20
17
16
15
14
1-2
29
26
Published 12-05-17, Control # 032-23
1
Item
2
3
4
5
6
7
8
9
12
10
11
13
1-100
18000 OPERATOR MANUAL
Description
1 Boom Top
2 Load Block
3 Boom Insert (typical)
4 Boom Insert (with Drum 1)
5 Drum 1 (Main Hoist)
6 Drum 6 (Luffing Jib Hoist)
7 Boom Butt (with Drums)
8 Drum 2 (Main Hoist)
9 Telescopic Boom Stop
10 Operator's Cab
11 Adapter Frame
12 Upperworks
13 Lowerworks
14 Crawler (both sides)
15 Rotating Bed Jacks (4 each)
16 Rotating Bed
17 Upper Counterweights
18 Live Mast
19 Mast Assist Arm (2 each with cylinders)
20 Drum 5 (Mast Hoist)
21 Drum 3 (Whip Hoist)
22 Drum 4 (Boom Hoist)
23 Mast Stop
24 Mast Straps
25 Fixed Mast
26 Load Drum Wire Rope
27 Boom Hoist Wire Rope
28 Equalizer
29 Boom Straps
FIGURE 1-2
