18000 OPERATOR MANUAL
2
12
1-101
Manitowoc
1
3
4
5
6
7
8
9
11
Published 12-05-17, Control # 032-23
Item Description
1 Live Mast
2 Upper Counterweights (both sides)
3 Fuel Tank
4 Hydraulic Tank
5 Engine
6 Hydraulic Pump (and Pump Drive)
7 Drum 5 (Mast Hoist)
8 Drum 3 (Whip Hoist)
9 Cab, Operator's
10 Crawler
11 Carbody Counterweights (both ends)
12 Carbody
13 Adapter Frame
14 Swing Drive (2 each)
15 Turntable Bearing (with External Ring Gear)
2
10
1-102
13
INTRODUCTION
14 11 15
FIGURE 1-3
1
9
1-3
