Manitowoc 18000 Operator's Manual page 260

SET-UP AND INSTALLATION
4-198
15
14
View F
4-201
17
4-203
Item Description
1 Jib Stop
2 Stop Pin
3 Pin w/Snap Pin
4 Jib Strut Butt
5 Jib Strut Top
6 Adjustable Link
7 Sling from Assist Crane
8 Pin w/2 Snap Pins
4-108
1
View B
Longer sling
attached to
strut top
7
5
8
6
4-202
4
Pin pendants
(14) here for
storage
12
View E
13
Item Description
9 Jib Straps and Links (as shipped)
10 Jib Straps and Links (assembled)
11 Lifting Lug
12 Connecting Pin w/Cotter Pins
13 Strut Support
14 3 ft, 3 in (0,99 m) Pendant
15 Pin w/2 Snap Pins
16 Pin w/2 Snap Pins
Published 12-05-17, Control # 032-23
4-200
10 (folded)
11
9
View C
10 (unfolded)
Item
17
18
19
20
21
22
23
18000 OPERATOR MANUAL
(shipping position)
2
1
View A
(stored)
16 13
View D
Description
Boom Top
Adjustable Link Strap
Strap Retaining Pin
Backstay Strap (#55 Boom)
Strap Connecting Link
Connecting Pin w/Collar and
Retaining Pins
Strap Shipping Pin
FIGURE 4-58
3
P2184
