18000 OPERATOR MANUAL

Hydraulic System Calibration

See Hydraulic System Calibration Procedures in this section.
PRESSURE SENDER CAL
CONTROL CAL
PUMP PRESSURE TEST
CHARGE PRESSURE

Speed/Torque

See Function Speed/Torque Adjustment in this section.
DRUM 1 SPEED 25 %
DRUM 2 SPEED 50 %
DRUM 3 SPEED 25 %
DRUM 4 SPEED 25 %

Accessory System

HANDLE +/-0 % ACC PRES
ACC VLV -0 % DM5 PRES
DM5 PMP +/-0 % DM5 SPD
VALVES 256 ACCUM P
The ACC system screen displays the following information:
• Drum 5 (mast hoist) control HANDLE command in
percent from neutral with + raise and - lower
• Accessory valve (ACC VLV) command in percent
• Drum 5 (mast hoist) pump (DM5 PMP) command in
percent from neutral with + raise and - lower
• Accessory system pressure (ACC PRES) in psi
• Drum 5 (mast hoist) pump pressure (DM5 PRES) in psi
• Drum 5 (mast hoist) drum speed (DM5 SPD) in RPM
• Accumulator system pressure (ACCUM PRES) in psi
• VALVES - displays
components that are active in bank:
Bank 1:
1 = Jacking command
2 = Rotating frame command
4 = Mast raise switch and mast hoist control handle
command is OFF
8 = Mast lower switch and mast hoist control handle
command is OFF
16 = Boom hinge pins in switch
Manitowoc
0% 0 0
0% 0
0% 0
0 0
DRUM 6 SPEED 25 %
TRAVEL SPEED 75 %
SWING SPEED 25 %
SWING TORQUE 60 %
psi
psi
rpm
psi ACC
binary number of system
Published 12-05-17, Control # 032-23
OPERATING CONTROLS AND PROCEDURES
32 = Boom hinge pins out switch
64 = Mast pins in switch
128 = Mast pins out switch
256 = Cab tilt up
512 = Cab tilt down
1028 = Raise mast arms from stored position
2056 = Lower mast arms to stored position
4096 = MAX-ER cylinder
8192 = Rigging winch command

Wireless

*REMOTE TxID 0000
SENSOR BANKS: 0
LOAD LINK TRAFFIC 0
REMOTE TRAFFIC 0
The WIRELESS screen displays the following information:
• REMOTE TxID - where the link identification code is
entered and displayed. To enter a link identification
code, press select. The cursor (*) appears next to
remote TxID. Press select again to enter identification
code area. Scroll up or down to enter 0 to 9 and/or A to F,
press select to move through each four positions.
• SENSOR BANKS - where the four banks listed below
display information shown in table.
1. Link 1 information
2. Link 2 information
3. Link 3 information
4. Hand-held radio remote control information
5. Block Level control information
Binary
Number
1, 2, or 4 Disregard information displayed.
8 RF link suspect.
16 Configuration data corrupt.
32 Internal CPU error.
64 Sensor voltage out of range.
(Not used with block level sensor)
128 Sensor battery low.
• LOAD LINK TRAFFIC where bank one is transmitter
identification and bank two property code (weight code
of link). The two banks work together and continuously
display information for each load link in immediate area.
64 0 128 160
0
0

WIRELESS

Information
3-63
