Table 4-2
Operating Limitations
Crane Configuration
• Crane on pedestals (rotating bed, adapter frame
and carbody).
• Live mast raised or lowered (NOTE 1).
• No assembly block.
• No crawlers.
• No counterweight.
• Crane on pedestals (rotating bed, adapter frame
and carbody).
• Live mast in operating range. (114° - 160°)
• Assembly block installed (NOTE 2).
• No crawlers installed (handling 1st crawler).
• No counterweight.
• Crane on pedestals (NOTE 3).
• First crawler installed and resting on ground.
• No counterweight.
• Crane on crawlers.
• Counterweight installed or removed.
• Handling loads with live mast.
NOTE 1 Maximum mast angle = 160°.
NOTE 2 Chain sling and 5-part line required.
NOTE 3 Pedestals installed only on side of carbody opposite 1st crawler.
• No carbody counterweight installed.
• Upper counterweight trays installed (no boxes installed).
• No carbody counterweight installed.
• Upper counterweight installed (trays and boxes).
• Carbody counterweight installed.
• Upper counterweight installed (trays and boxes).
• No carbody counterweight installed.
• Upper counterweight trays installed (no boxes installed).
• No carbody counterweight installed.
• Upper counterweight installed (trays and boxes).
• Carbody counterweight installed.
• Upper counterweight installed (trays and boxes).
NOTE 4 Applies to 100 ft (30.5 m) and 140 ft (42.7 m) mast.
Contact the Manitowoc Crane Care Lattice Team for swing and travel specifications not listed.
