Manitowoc 18000 Operator's Manual page 210

SET-UP AND INSTALLATION
Pick Straps Midway
Between These Two
Points, if Necessary
4-210
4
P2180
4-58
A1286
View C
(shipping)
3
Item Description
1 #55 Boom Top
2 #49 Jib
3 Jib Stop
4 Adjusting Rod
5 Jib Stop Locking Pin
6 Jib Stop Luffing Location
7 Upper Jib Point
8 Connecting Pin w/ Cotter Pins (2 places)
Published 12-05-17, Control # 032-23
4-211
View B
5
P2181
Hole A
18000 OPERATOR MANUAL
7
8
View A
6
3
Hole B
FIGURE 4-32
