18000 OPERATOR MANUAL
B – Accessory Controls
See Figure 3-5 for the following controls.

B1. Cab Tilt Switch

PRESS and hold TOP of rocker to RAISE front of cab.
CENTER rocker to LOCK cab in position
PRESS and hold BOTTOM of rocker to LOWER front of cab.
WARNING
Moving Cab Hazard!
Warn personnel to stand clear of operator's cab while
tilting.
• Personnel can lose balance and fall.
• Personnel can be crushed between cab and railing.
Pinch Point Hazard!
To prevent injury from moving cab door:
• Do not open cab door while cab is tilted up. Door will
spring back with considerable force.
• Always open and close cab door when cab is level.
See cab door adjustment in this section.

B2. Panel Lights Switch

Press TOP of rocker to turn ON panel lights.
Press BOTTOM of rocker to TURN OFF panel lights,

B3. Dome Light Switch

Press TOP of rocker to TURN on dome light.
Press BOTTOM of rocker to TURN OFF dome light.

B4. Climate Control

Provides cab temperature control from 55–95°F (13-35°C).
a. ON—Depress to turn on climate control system.
The LED will illuminate and display the current
temperature setting.
b. OFF—Depress to turn off climate control system.
c. AUTO—Depress to place system in fully automatic
temperature control mode, to include fan speed.
The system will adjust blower fan speed to the
lowest setting necessary to maintain the selected
Manitowoc
cab temperature. A panel indicator light illuminates
when this mode is on.
d. DEF (defrost)—Depress to energize the A/C system
to allow for rapid de-humidification of cab. A panel
indicator light illuminates when this mode is on.
e. FAN UP/DOWN—Overrides AUTO mode. Depress
to increment fan speed up or down in 11 steps. The
LED indicates the setting as a percent between HI
and LO. The selected fan speed is maintained until
changed or the AUTO mode is turned on.
f. TEMPERATURE UP/DOWN—Depress to raise or
l o w e r t h e t e m p e r a t u r e s e t t i n g . T h e s y s t e m
maintains the cab temperature as close as possible
to the selected temperature.
To change the display temperature from Fahrenheit
to Celsius or back, depress TEMPERATURE UP/
DOWN buttons simultaneously.
g. LED
h. FAULT CODES—To display fault codes, press ON
button three times. Any active fault codes are shown
on the LED.
Displayed fault codes are:
-
-
-
-
-
-
-

B5. Overhead Windshield Wiper Switch

B6. Front Windshield Wiper and Washer Switch

Each switch has several positions:
• Down — OFF
• Middle — 6 INTERMITTENT positions depending how
far toggle is moved
• Up — HIGH speed
PRESS and hold front windshield wiper switch to SPRAY
washer fluid on front windshield.
The windshield washer tank is mounted on the right side of
the cab support. Fill the tank with a quality brand washing
solution that will not freeze during cold weather.
Published 12-05-17, Control # 032-23
OPERATING CONTROLS AND PROCEDURES
E00 — No Faults
E01 — Cab Sensor Shorted
E02 — Cab Sensor Open
E03 — Evaporator Probe Shorted
E04 — Evaporator Probe Open
E09 — Water Valve Shorted
E10 — Water Valve Open
