SET-UP AND INSTALLATION
Install Rotating Bed Catwalks and Steps
(Past Production)

Side and Rear Catwalks

See Figure 4-14, View D for the following procedure.
1. Using chain slings from assist crane connected to four
lifting holes in catwalk, lift catwalk (2a or 2b) into position
so fixed pins (5) in catwalk fully engage hooks on side or
rear of rotating bed.
2. Install quick-release pins (6) to lock catwalk in place.
3. Level catwalk as required after installation with two
leveling bolts (7).
4. Repeat preceding steps for each catwalk.

Steps

See Figure 4-14, View B for the following procedure.
4-20
1. Using nylon slings from assist crane, lift steps (1) into
position alongside either catwalk.
2. Slide tubes at top of steps through sleeves (9) on
underside of catwalk.
3. Install quick-release pins (10) to lock steps in place.
4. Repeat preceding steps for steps on other side.

Cab Rear Catwalk

See Figure
1. Using nylon slings from assist crane, lift catwalk (3) into
position so hooks (11) in catwalk fully engage fixed pins
(12) on rear of cab.
2. Level the catwalk as required after installation with two
leveling bolts (14).
Published 12-05-17, Control # 032-23
18000 OPERATOR MANUAL
4-14, View C for the following procedure.
