Manitowoc 18000 Operator's Manual page 222

SET-UP AND INSTALLATION
4-160
17 16
P1927a
View M
Front of Carbody
P1963
View L
(2 places)
4-70
View G
19 18
View K
(2 places)
Item
14
15
22
16
17
23
18
19
20
21
22
23
21
Align Narrow Edge with
Front and Rear or Carbody
Published 12-05-17, Control # 032-23
View H
Center of Crawler
Do Not Block
Between Pads
P2493
P2495
19
Do Not Block Here
at Either End
Directly Under a Pad As
Close as Possible to Both
20
Ends of Crawler Frame
Description
Blocking — 15 in (381 mm) Wide by Same Width as Crawler Pads
Left Crawler Pins Control
Right Crawler Pins Control
Crawler Alignment Lug
Carbody Frame
Crawler Hook
Carbody Pin
Carbody Pedestal
Support Pad
Adjusting Screw
18000 OPERATOR MANUAL
P2494
14
Directly Under
Center Pad
View J
Both Ends of Crawler
14
FIGURE 4-36 continued
