Gps - Maintenance Practices - Eclipse EA500 Maintenance Manual

AMM-34-50-10-051-A-801
1. General
A. The purpose of this task is to provide instructions for configuring the GPS 400W for use
on the Eclipse Model 500 aircraft.
B. If ADS-B OUT is installed, GPS software must be at least at the following level:
SW P/N 006-B1144-23 Main SW v5.03
SW P/N 006-B0803-20 GPS WAAS SW v5.0.
NOTE: As applicable, make sure that the GPS software is in same configuration as it
was when the removal task was completed. If necessary, update GPS software
to the required level.
2. Equipment and Materials
Ground Power Unit (GPU) (AllStar 450, AllStar G.S.E., Hobart GPU-400, Hobart GPU- 600, or
Bycan PS-28100)
Weight-on-Wheels (WOW) Box (EAI, 87-117390-1001) or AMC 2.4.01 (or higher).
3. Job Set-Up
SUBTASK AMM-34-50-10-051-A-921-001
A. Make aircraft safe for maintenance. Refer to
Maintenance.
B. Connect the ground power cart to electrical utility connector. Connect the ground power
cart to the aircraft EXTERNAL POWER RECEPTACLE and turn on power on the cart.
Ensure the green EXT POWER light on the IPL is on. But do not turn on aircraft's power.
Refer to AMM-24-40-00-051-801 – External Power - Maintenance Practices.
C. Connect Weight On Wheels (WOW) box or Aircraft Maintenance Computer (AMC) and
set to W-On-W for start of test. Refer to
(WOW) Box - Connect/Disconnect.
D. On the IPL set the SYS BATT and START BATT switches to the ON (up) position and
BUS TIE to AUTO (up) position. On the right side of the MFD, press the PROCEED soft
key. Clear any "MASTER CAUTIONS" and "MASTER WARNINGS" as needed.
E. On the ECB AVIONICS synoptic page. Make sure the following ECBs are AUTO-ON:
• ECB - GPS 1 (R FWD Bus) or
• ECB - GPS 2 (L FWD Bus)
EFFECTIVITY: 0001-0262, POST SB 500-99-005; AND
0266-0267; ALL POST MB 500-31-018
EA500 Aircraft Maintenance Manual — 06-117751

GPS - MAINTENANCE PRACTICES

Table 201. Special Tools and Equipment
Name and Part Number
AMM-20-00-04-051-801 – Weight On Wheels
© 2020 Eclipse Aerospace, Inc.
Temporary Revision No. 34-21
AMM-20-00-01-051-801 – Make Safe For
34-50-10
CONFIG A
Page 201
Sep 30/20
