(6) Set both the left and right PFD Baro to 29.92 by pressing the BARO SET knob on the
Autopilot Control Panel (ACP). Make sure the baro setting matches on the left and
right PFD.
(7) Make sure that the ADC 3 is displayed on the MFD ADI.
CAUTION: IF TRANSPONDER(S) NOT SET TO "STBY", THE AIRCRAFT WILL CAUSE
NUISANCE TRANSPONDER TRANSMISSIONS TO THE LOCAL AIRFIELD
AND OTHER AIRCRAFT.

4. Pitot and Static System Leak Test

SUBTASK AMM-34-10-00-071-701-001
* * * ALL
CAUTION: DO NOT PRESSURIZE THE AIRCRAFT DURING TESTING.
NOTE: If a Barfield Pitot/Static Tester DPS450 is used for this test complete paragraph
A. If a Barfield Pitot/Static Tester DPS500 is used, go to paragraph B.
A. Pitot and Static System Leak Test with Barfield Pitot/Static Tester DPS450:
Procedure is given for the left side and is the same for the right side.
Refer to Fig. 501, Sheet
CAUTION: DO NOT OVER TIGHTEN HOSES. DAMAGE MAY OCCUR TO TEST
EQUIPMENT. HOSES SHOULD BE SNUG.
CAUTION: THE LEAK TEST CAN BE ACCOMPLISHED WITH ELECTRICAL
POWER OFF. MAKE SURE THAT IF THE WOW BOX IS CONNECTED,
THE SWITCHES ARE SET TO WONW DURING THIS TEST IF
ELECTRICAL POWER IS USED. WITH WEIGHT OFF WHEELS, THE
HEATERS ARE COMMANDED ON BY THE AIRCRAFT COMPUTER
SYSTEM. IF THE PITOT/STATIC HEAT ECBS ARE NOT COLLARED
OFF, HARM TO PERSONNEL OR AIR DATA TEST EQUIPMENT CAN
OCCUR.
NOTE: Refer to step (1) if using Air Data Accessories Kit ; (Nav Aids PN
ADA500945) or step (2) if using Air Data Accessories Kit (NavAids P/N
ADA500MD-945.
(1) Connect the Barfield Pitot/Static Tester DPS450 to the aircraft using the Air Data
Accessories Kit ; (Nav Aids PN ADA500945) as follows:
(a) Install the Pitot/Angle of Attack (AOA) Probe Adaptor (Nav Aids,
APA94520-4-4-4)
needed, lubricate with Pitot adaptor lubricating fluid (Part Number LF5050).
EFFECTIVITY: NOTED
EA500 Aircraft Maintenance Manual — 06-117751
1.
(7) with the label TOP facing up on the Pitot/AOA probe. If
© 2020 Eclipse Aerospace, Inc.
Temporary Revision No. 34-21
34-10-00
Page 504
Sep 30/20
