4. Procedure with UC-584 Antenna Couplers
SUBTASK AMM-34-50-20-071-A-701-001
A. Do adjustment/test of the Transponder System as follows:
(1) Perform job setup, refer to
(2) Push ECB BY SYSTEM soft key. Scroll to FLT CTRLS using outer knob. Push inner
knob to select. Scroll to the listed ECB using outer knob and highlight. Push
"COLLAR" Soft key. Press "CONFIRM COLLAR" soft key.
• ECB - NOSE LDG GEAR (L AFT Bus)
• ECB - L MAIN LDG GEAR (L AFT Bus)
• ECB - R MAIN LDG GEAR (L AFT Bus)
(3) Set WOW Box to W-off-W.
NOTE: Transponders only turn on with Weight-off-Wheels.
(4) Set both left and right PFD baro set to 29.92 on Autopilot Control Panel (ACP) by
pressing BARO SET knob.
B. Transponder-1 Setup using Transponder Test Set, IFR6000
(1) Press the bottom right rocker switch on the left PFD to select XPDR.
NOTE: The XPDR select page times out and switches back to the COM page after
30 seconds. Select XPDR page from time to time during this test.
(2) Press ACTIVE softkey (upper right button) on the left PFD to select XPDR1.
(3) CODE status box on the left PFD and right PFD shows 1200.
(a) To change CODE, scroll to XPDR using softkey. Use outer knob to highlight and
inner knob to change numeric values.
(4) Press MODE softkey on the left PFD to select ON.
(5) Press the bottom right rocker switch on the right PFD to select XPDR.
NOTE: The XPDR select page times out and switches back to the COM page after
30 seconds. Select XPDR page from time to time during this test.
(6) Press ACTIVE softkey (upper right button) on the right PFD to select XPDR1.
(7) Set CODE to 1300, scroll to XPDR using softkey, and use the outer knob to highlight
and inner knob to change numeric values.
(8) CODE status box on the Left PFD and Right PFD shows 1300.
NOTE: Upon completion of Right PFD test, return CODE to 1200.
(9) Press MODE softkey on the right PFD to select ON.
(10) Using the pilot's keyboard, perform the following steps:
(a) Press XPDR1.
• Keyboard XPDR1 LED is lit.
(b) Press ON.
EFFECTIVITY: 0001-0104, 0113-0115, 0120, 0123-0124
PRE SB 500-99-002 AND SB 500-99-005
EA500 Aircraft Maintenance Manual — 06-117751
SUBTASK AMM-34-50-20-071-A-921-001-B.
© 2020 Eclipse Aerospace, Inc.
Temporary Revision No. 34-21
34-50-20
CONFIG A
Page 504
Sep 30/20
