(7) Power up the aircraft.
NOTE: After initial system installation, the initial acquisition of GPS position can take
up to 20 minutes. Subsequent acquisitions should take no more than 150
seconds.
(8) If installed, make sure that the ADS-B FAIL indicator is illuminated in white color.
Refer to Fig. 502, Sheet
150 seconds or less after power up.
(9) Make sure that no ADS-B related CAS messages are displayed.
NOTE: It may take up to 150 seconds for the CAS messages to clear.
(10) If installed, allow for the amber INTEG message on the Left GPS 400W unit to
extinguish.
NOTE: It may take up to 150 seconds for the GPS unit to obtain the GPS position
and extinguish the INTEG message.
(11) Make sure that the Baro Correction is set to 29.92 inHg. Use the Autopilot Control
Panel (ACP) to set.
(12) On either PFD, select transponder under test as ACTIVE transponder and enter
transponder test squawk code as assigned by Air Traffic Control for the test.
Transponder should be in STBY mode.
(13) Set WOW Box switches to W-off-W (airborne). Transponder should transition to ALT
mode.
SUBTASK AMM-34-50-20-071-C-701-006
* * * ALL POST MB 500-31-016, MB 500-31-018 AND MB 500-34-030
A. ADS-B Out Functional Test
(1) Do ADS-B Out Test Set-Up. Refer to
(2) In order to check that ADS-B OUT function is active, for each installed transponder,
except for noted limitation, perform the following test using IFR 6000 or an equivalent
test set.
Limitation: If the aircraft is equipped with Garmin GPS 400W, this test applies to
Transponder 1 (XPDR 1) only.
(a) On IFR 6000, press RUN TEST soft key to start test. When a specific extended
squitter BDS is captured, AVAIL will be displayed to the right of the BDS name.
Use Data Keys to select specific BDS and press BDS DATA soft key to display
selected BDS screen.
Press Return soft key to return to ADSB MON list screen or press PREV TEST or
NEXT TEST soft keys to select specific ADS-B MON BDS screens.
(b) Select BDS 0,5 AIRBORNE POS and check the following data:
AA = matches aircraft ICAO code displayed on the MFD Settings Page
LAT = comparable to the aircraft latitude.
LON = comparable to the aircraft longitude.
BARO PRES ALT = matches aircraft altitude displayed on the L PFD within ±125
ft.
EFFECTIVITY: NOTED
EA500 Aircraft Maintenance Manual — 06-117751
1. Make sure the ADS-B FAIL indicator extinguishes within
